- Page 1 Installation Instructions and User Guide Thermostatic Recessed Three Control Shower Valve with Integral Twin Stopcocks Models covered: SHP02, SSOBC02 & SLYCG02 Please keep this booklet for future reference. Installer, when you have read these instructions please ensure you leave them with the user.
-
Page 2: Table Of Contents
Contents Thank you for choosing Heritage, the UK’s market leader for classic bathroom products. To ensure this product works to its full potential, it needs to be fitted correctly. These fitting instructions have been created to give you all of the information you need. If you need any further help, please do not hesitate to give us a call on 0844 701 8503. -
Page 3: Important Safety Information
Important Safety Information • Please read these instructions thoroughly and retain for future use. • All products manufactured and supplied by Heritage are safe provided they are installed, used correctly and receive regular maintenance in accordance with these instructions. • If you are in any doubt about your ability to install this product safely you must employ the services of an experienced qualified plumber. -
Page 4: General Information
General Information This product has been tested to the Water Regulations Advisory Scheme (WRAS) and satisfies the requirements of the Water Supply (Water Fittings) Regulations 1999 and current bylaws. For full Installation Requirements & Notes (IRN) please visit www.wras.co.uk/directory. BS7600 recommends the temperature of stored water should never exceed 65ºC. A stored water temperature of 60ºC is considered sufficient to meet all normal requirements and will minimise the build up of lime scale in hard water areas. -
Page 5: Product Features
Product Features 1. Single outlet stopcock This single outlet stopcock controls the on / off and flow of water to a single outlet e.g. Rigid riser. 2. Temperature control Adjustable temperature control. Turn the handle clockwise for a cooler tem- perature. -
Page 6: Specifications
Specifications Inlet connections: 15mm compression with 150mm between centres. Minimum working pressure: 0.2 bar Note: This product has been designed to deliver a high flow of water on low pressure systems, however depending on the installation, type of system and shower accessories used a higher pressure maybe required to optimise the showering experence. -
Page 7: Pack Contents
7. Inserts x2 8. Flow regulators x2 9. Filter washers x2 10. Wall outlet x1 11. Shrouds x3 3 (SHP02) 3 (SSOBC02) Need help? Give us a call on 0844 701 8503 and speak to one of our trained advisers. -
Page 8: Prior To Installation
Prior to Installation Flow Regulators This shower valve is supplied with a 5 and 7 litre per minute flow regulator loose in the box which must be fitted if the shower valve is installed in conjunction with an instantane- ous water heater / combination boiler. Filter Washer With both flow regulators fitted and by... -
Page 9: Installation
Installation - Shower Valve This installation method should be used to install the CAS, ORB, PIV & TRI SHC3STP Once the shower valve has been installed the wall surface should be finished and tiled upto the valve. Rear access is required to allow for future servicing and maintenance of the valve filters. - Page 10 Installation - Shower Valve 4. Finish wall surface Plasterboard and tile the cavity wall ensuring there is a gap between the tiles and the shower valve 5. Fit concealing plate and handles Run a bead of waterproof silicon sealant around the inner edge of the concealing plate. Slide the concealing plate onto the shower valve and apply firm pressure to ensure to silicon sealant spreads.
-
Page 11: Wall Outlet
Installation - Wall Outlet Fitting the Wall Outlet There are two methods of fixing the wall outlet Backnut depending on the type of wall: a: With rear access once wall finished Fit the rubber washer to the back of the wall Rubber outlet, place the assembly through a 25-30mm seal... -
Page 12: Operating The Shower
Operating the Shower 1. Single outlet stopcock This single outlet stopcock controls the on / off and flow of water to a single outlet e.g. Rigid riser. Turn the handle anti-clockwise to turn the flow of water on. Turn the handle clockwise to turn the flow of water off. -
Page 13: Maintenance
Maintenance General Cleaning Your fitting has a high quality finish and should be treated with care to preserve the visible surfaces. All surfaces will wear if not cleaned correctly, the only safe way to clean your Unscrew product is to wipe with a soft damp cloth. anti-clockwise Stains can be removed using washing up liquid. -
Page 14: Adjusting The Temperature
Adjusting the Temperature Adjusting the Temperature temperature of the water with a The shower valve has been factory set to thermometer. If the temperature is not cor- 42ºC with equal (balanced) hot and cold rect, re-calibrate the shower valve: water supply pressures, with the hot water 1. -
Page 15: Troubleshooting
Troubleshooting Symptom Cause Remedy No flow or low Check showerhead, hose and Clean as necessary, refer to flow rate and filters for any blockage. Maintenance section (page 13). / or varying Partially closed stop or service Open stop or service valve. temperatures. - Page 16 Troubleshooting Symptom Cause Remedy Maximum water Maximum water temperature set Reset maximum water temperature. temperature too incorrectly. Refer to ‘Maximum Temperature hot or cold. setting’ in Maintenance section (page 13) and ‘Adjusting the Temperature’ (page 14) Outlet water Inlet filter is partially blocked. Check inlet filters for any blockages temperature too and clean as necessary.
-
Page 17: Notes
Notes Please use this space to add any notes you or your installer may have regarding the plumbing system / installation of this product. Need help? Give us a call on 0844 701 8503 and speak to one of our trained advisers. -
Page 18: Guarantee
Guarantee When you buy a Heritage product, you • Repair under this guarantee does not can be confident that it not only features a extend the original expiry date. The beautiful design, distinctive, classic design, but guarantee on any replacement parts or that it has also been made to the very highest product ends at the original expiry date. - Page 19 Guarantee • Need help? Expert plumbing engineers If this product does not function correctly If we can’t solve the problem over the ‘phone when first used, contact Heritage Custom- or with a spare part, then we’ll send out one er Service on 0844 701 8503 where our of our engineers to take a look.
- Page 20 Birch Coppice Business Park Dordon Tamworth Staffordshire B78 1SG Web: www.heritagebathrooms.com Email: technical@heritagebathrooms.com Tel: 0844 7018503 Part Number: FI: SHP02/SSOBC02/SLYCG02 Issue: D3...
