Dawlish Tap Range
Installation Instructions
and User Guide
Models covered:
Basin Taps
TDCC00 / TDCG00 / TDCN00
Short Nose Basin Taps
TDCCS00 / TDCGS00/ TDCNS00
Bath Taps
TDCC01 / TDCG01/ TDCN01
Bath Filler
TDCC072 / TDCG072/ TDCN07
Bath Shower Mixer
TDCC02 / TDCG02/ TDCN02
Please keep this booklet for future reference.
Installer: when you have read these instructions please
ensure you leave them with the user.
Advertisement
Table of Contents
Related Manuals for Heritage Bathrooms TDCC00
Summary of Contents for Heritage Bathrooms TDCC00
- Page 1 Dawlish Tap Range Installation Instructions and User Guide Models covered: Basin Taps TDCC00 / TDCG00 / TDCN00 Short Nose Basin Taps TDCCS00 / TDCGS00/ TDCNS00 Bath Taps TDCC01 / TDCG01/ TDCN01 Bath Filler TDCC072 / TDCG072/ TDCN07 Bath Shower Mixer TDCC02 / TDCG02/ TDCN02 Please keep this booklet for future reference.
-
Page 2: Table Of Contents
Contents When you buy a Heritage product, you can be confident that it not only features a beautiful, distinctive, classic design, but that it has also been made to the very highest quality standards. To ensure that it works to its full potential, it needs to be fitted correctly. These fitting instructions have been created to give you all of the information you need and, if you need any further help, please do not hesitate to give us a call on 0330 026 8503. -
Page 3: Important Safety Information
NOTE:- Nominally equal (balanced) inlet supply pressures are recommended for optimum Performance of mixer taps. All products manufactured and supplied by Heritage Bathrooms are safe to use provided that they are installed, operated and receive regular maintenance in accordance with these instructions. This product needs to be installed in accordance with, and meet the requirements of the Water Supply (Water Fittings) Regulations 1999 and current by- laws. -
Page 4: Dimensions
Dimensions Basin Taps (TDCC00/TDCG00/TDCN00) Short Nose Basin Taps Bath Taps (TDCC01/TDCG01/TDCN01) (TDCCS00/TDCGS00/TDCNS00) - Page 5 Dimensions Cont. Bath Filler (TDCC072/TDCG072/TDCN07) Bath Shower Mixer (TDCC02/TDCG02/TDCN02)
-
Page 6: Basin Taps & Bath Taps
Installation – Basin / Bath Taps 1. Identify all components are present prior to starting installation. 2. Using the washer (10) and backnuts (11) secure the taps to the basin by tightening the backnuts onto the pre-fitted threaded tails (9). A suitable spanner may be required to fully tighten the backnuts (11). -
Page 7: Bath Filler / Bath Shower Mixer
Installation – Bath Filler / Bath Shower Mixer Handset Washer Hose Backnut Cradle Assembly Handset Holder Diverter Assembly Screw Elbow Assembly Shroud Pillar Assembly Rawl Plug... -
Page 8: Installation
Installation – Bath Filler / Bath Shower Mixer Cont. * Bath shower mixer only 1. Identify all components are present prior to starting installation. 2. Connect the elbow assembly (5) to the tap body, then connect the pillar assembley (6) to the elbow (5). -
Page 9: Maintenance
Maintenance General Cleaning Heritage products are made from premium materials, with hand polishing, PVD, EPD and electroplated finishes. Your product should be regularly cleaned with warm water, a mild pH-neutral liquid soap, and polished with a soft cloth. Any residues from soap, toiletries etc. should be rinsed off straight after use. - Page 10 Maintenance Cont. Replacing the Valves Indice If your fitting begins to leak the following should be carried out; Screw & Washer Isolate both hot and cold water supplies to the tap by either: Handle • Turning the water supply off at the mains stopcock or Shroud •...
-
Page 11: Troubleshooting
Troubleshooting Symptom Cause Remedy No flow or poor flow rate. Partially closed isolation valve. Open isolation valve. Instantaneous water heater cycles on Increase water flow rate or pressure and off as flow rate or pressure is too through system. low. Head of water is below the Refer to specification for minimum minimum distance required. -
Page 12: Guarantee
Heritage Bathrooms Guarantee G UA R A N T E E The confidence we have in the quality of our products and services enables us to offer a free peace-of-mind product guarantee from 2 years up to a lifetime guarantee against any manufacturing faults, with proof of purchase. -
Page 13: Notes
Notes Please use this space to add any notes which you or your installer may have regarding the plumbing, installation, and/or servicing of this product:... - Page 14 Notes Please use this space to add any notes which you or your installer may have regarding the plumbing, installation, and/or servicing of this product:...
- Page 15 Notes Please use this space to add any notes which you or your installer may have regarding the plumbing, installation, and/or servicing of this product:...
- Page 16 Email us 0330 026 8503 Call us www.heritagebathrooms.com Website UK: Heritage Bathrooms, Pooley Hall Drive, Birch Coppice Business Park, Dordon, Tamworth B78 1SG EU: Masco Europe S.à.r.l., 14 Rue Strachen, 6933 Mensdorf, Luxembourg.
