ADS-B FDL-978 Series and
Lite Series Installation Manual
Document No. 87343 Rev G
The items included in the Blade Type Antenna Installation Kit (P/N 87003-00) are listed below:
Part Number
87005
86966
0129-0017-00
0123-0012-00
The items included in the Ball and Stick Type Antenna Installation Kit (P/N 87004-00) are listed
below:
Part Number
85937
86966
0129-0017-00
The items for the FDL-978 Series included in the TSO-C190 GPS Antenna Installation Kit (P/N
87360-00) are listed below. The TSO-C190 antenna is only recommended to accommodate
future upgrades with TSO-C145c Class 2, 3, and 4 navigation sensors in the transceiver
system.
Part Number
86735
0129-0017-00
0123-0012-00
The items for the FDL-978 Series included in the TSO-C144 GPS Antenna Installation Kit (P/N
87360-10) are listed below.
Part Number
81194
0129-0017-00
0123-0012-00
1-16
Qty
1
Blade Type UAT Antenna
1
BNC RG142 Male Crimp Connector
1
TNC Connector
25 ft RG-142 Coax Cable
Qty
1
Ball and Stick Type UAT Antenna
1
BNC RG142 Male Crimp Connector
1
TNC Connector
Qty
1
Antenna GPS SBAS (WAAS) DO-301 TSO-C190 and
TSO-C144
2
TNC Connector Male RG-142 Crimp
25 ft
RG-142 Coax Cable
Qty
1
Antenna GPS SBAS (WAAS) DO-228 TSO-C144
2
TNC Connector Male RG-142 Crimp
25 ft
RG-142 Coax Cable
Description
Description
Description
Description
FFS Copyright © 2016 All rights reserved.
