Table of Contents
loading
Need help?

Need help?

Do you have a question about the GLO-RAY GR Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Hatco GLO-RAY GR Series

  • Page 1 Keep this manual in a safe location for pregunte a su supervisor. Almacenar future reference. este manual en una localización segura para la referencia futura. © 2008 Hatco Corporation...
  • Page 2: Table Of Contents

    (Summer Hours: June to September – in the spaces below. Please have this information 8:00 a.m. to 5:00 p.m. C.S.T. available when calling Hatco for service assistance. Monday through Thursday 8:00 a.m. to 2:30 p.m. C.S.T. Friday) Model No. ________________________________ Telephone: (800) 558-0607;...
  • Page 3: Important Safety Information

    Refer to specific made by a qualified, licensed electrician. installation and mounting information in this manual for proper clearances. • Units equipped with a cord and plug supplied by Hatco must be plugged into a properly • Make sure follow installation...
  • Page 4: Model Designations

    Corian ® and similar products (other than section of this manual. stainless steel) is not covered under the Hatco warranty. Contact the manufacturer of the base material for temperature limits and application information before installing the unit. Use non-abrasive cleaners only. Abrasive...
  • Page 5: Model Descriptions

    All manuals and user guides at all-guides.com MODEL DESCRIPTIONS Hatco Glo-Ray ® Infrared Strip Heaters keep hot foods at optimum serving temperatures longer. Foods do not dry out or become discolored; even the most delicate dishes hold that “just-prepared” look. The Glo-Ray pre-focused heat pattern directs...
  • Page 6: Specifications

    All manuals and user guides at all-guides.com SPECIFICATIONS Electrical Rating Chart — GRH Models Electrical Rating Chart — GR Models Model GR-18 Watts: 250 Shipping Weight: 7 lbs. (3 kg) Model GRH-18 Watts: 350 Shipping Weight: 7 lbs. (3 kg) Voltage Voltage Amps...
  • Page 7 All manuals and user guides at all-guides.com SPECIFICATIONS Electrical Rating Chart — GRA Models Electrical Rating Chart — GRAH Models Model GRA-18 Model GRAH-18 Watts: 250 Shipping Weight: 6 lbs. (3 kg) Watts: 350 Shipping Weight: 6 lbs. (3 kg) Voltage Voltage Amps...
  • Page 8 All manuals and user guides at all-guides.com SPECIFICATIONS Electrical Rating Chart — GRAHL Models Electrical Rating Chart — GRAL Models Model GRAL-18 Model GRAHL-18 Watts: 370 Shipping Weight: 9 lbs. (4 kg) Watts: 470 Shipping Weight: 9 lbs. (4 kg) Voltage 120/208 120/240...
  • Page 9 All manuals and user guides at all-guides.com SPECIFICATIONS Electrical Rating Chart — Electrical Rating Chart — GRA-XXD Models GRAH-XXD Models Model GRA-18D Watts: 500 Shipping Weight: 14 lbs. (6 kg) Model GRAH-18D Watts: 700 Shipping Weight: 14 lbs. (6 kg) Voltage Voltage Amps...
  • Page 10 All manuals and user guides at all-guides.com SPECIFICATIONS Electrical Rating Chart — Electrical Rating Chart — GRAL-XXD Models GRAHL-XXD Models Model GRAHL-18D Watts: 820 Shipping Weight: 14 lbs. (6 kg) Model GRAL-18D Watts: 620 Shipping Weight: 14 lbs. (6 kg) Voltage 120/208 120/240...
  • Page 11 All manuals and user guides at all-guides.com SPECIFICATIONS Electrical Rating Chart — GRN Models Electrical Rating Chart — GRNH Models Model GRN-18 Model GRNH-18 Watts: 250 Shipping Weight: 6 lbs. (3 kg) Watts: 350 Shipping Weight: 6 lbs. (3 kg) Voltage Voltage Amps...
  • Page 12: Dimensions

    All manuals and user guides at all-guides.com SPECIFICATIONS Dimensions Width Depth Depth Height Models GR and 18″ – 96″ 6″ 23″ 2-1/2″ (457 – 2438 mm) (152 mm) (584 mm) (64 mm) GRA and 18″ – 144″ 6″ 23″ 2-1/2″ GRAH (457 –...
  • Page 13: Installation

    ® and similar products (other than Do not mount units longer than 60″ (1524 mm) stainless steel) is not covered under the Hatco on T-legs or C-legs. warranty. Contact the manufacturer of the base material for temperature limits and application Over Steam Table information before installing the unit.
  • Page 14: Mounting Height Requirements

    All manuals and user guides at all-guides.com INSTALLATION Mounting Height Requirements Assembly Glo-Ray Strip Heaters are shipped with most Add 3″ for components pre-assembled. Dual units are 4″–6″ units with lights. (102–152 mm) available with a required 3″ (76 mm) or 6″ (152 mm) spacer pre-assembled at the factory.
  • Page 15 All manuals and user guides at all-guides.com INSTALLATION 5. Align the two mounting holes on the small “T” of Removed the T-Leg with the two holes on the end of the Hanger Tabs unit. Secure the leg to the unit with the two screws removed in the previous step.
  • Page 16: Minimum Clearance Requirements

    All manuals and user guides at all-guides.com INSTALLATION Minimum Clearance Requirements for Combustible Surroundings Models Pass-Through Shelf GRA and 10″ 3″ 1″ GRAL (254 mm) (76 mm) (25 mm) GRAH and 13-1/2″ 3″ 1″ GRAHL (343 mm) (76 mm) (25 mm) NOTE: Dual strip heaters cannot be installed in combustible surroundings.
  • Page 17: Permanent Surface Mount

    All manuals and user guides at all-guides.com INSTALLATION Permanent Surface Mount NOTE: The adjustable stands can be raised or lowered by turning the locking set screw Tubular stand mounting permanently attaches the counterclockwise one turn with an Allen unit to a countertop or serving table. All wiring may wrench, and then raising or lowering the be concealed within one of the tubular stands.
  • Page 18: Undershelf Mounting

    (not supplied If the shelf has a rolled or flanged edge, use the by Hatco). optional adjustable angle brackets to mount the unit NOTE: Two pairs of brackets will be needed for below the lowest part of the rolled or flanged edge of dual units.
  • Page 19: Ceiling Mounting

    NOTE: The strength of the chain supplied by Hatco on the unit (see Figure 27). is sufficient to hold the weight of the unit securely only when mounted properly.
  • Page 20: Electrical Wiring Hook-Up

    Strip heaters equipped with incandescent lights ELECTRIC SHOCK HAZARD: Units equipped that require a circuit breaker larger than 20 amps with a cord and plug supplied by Hatco must be for the heat element must have a separate circuit plugged into a properly grounded electrical...
  • Page 21: Operation

    All manuals and user guides at all-guides.com OPERATION General Lights On models equipped with display lights, move the Use the following information to operate the Glo- light ON/OFF toggle switch to the ON position to Ray strip heaters. turn on the lights. WARNING Read all safety messages in the IMPORTANT SAFETY...
  • Page 22: Maintenance

    For 120, 120/208, 120/240 and 100/200 Volt applications, use Hatco part Use non-abrasive cleaners only. Abrasive number 02.30.043.00. For 200, 220, 230 cleaners could scratch the finish of the unit, and 240 Volt units use Hatco part number marring appearance making 02.30.058.00.
  • Page 23: Accessories

    ACCESSORIES Remote Mounted Control Boxes Indicator Light Hatco Remote Mounted Control Boxes (RMBs) are An optional indicator light is available installed on available in various sizes and configurations for use either side of the unit. The indicator light provides an with the strip heaters.
  • Page 24: Troubleshooting Guide

    If power cord connected, check for damage to cord. If power cord connected, check power outlet. Switch is defective. Contact Authorized Service Agent or Hatco for assistance. Wiring is open. Contact Authorized Service Agent or Hatco for assistance. Heating element defective.
  • Page 25 Glo-Ray Installation and Operations Manual. Relocate switches to a cooler zone if installation is incorrect. Switches used are not Hatco Genuine Hatco Parts are specified to supplied. operate safely and properly in the environment in which they are used.
  • Page 26: Hatco Limited Warranty

    PATENT OR OTHER INTELLECTUAL PROPERTY accordance with Hatco’s written instructions or 18 RIGHT INFRINGEMENT. Without limiting the months from the date of shipment from Hatco. Buyer generality of the foregoing, SUCH WARRANTIES must establish the product’s purchase date by DO NOT COVER: Coated incandescent light bulbs, returning Hatco’s Warranty Registration Card or by...
  • Page 27 All manuals and user guides at all-guides.com NOTES Form No. GRM-0508...
  • Page 28: Authorized Parts Distributors

    All manuals and user guides at all-guides.com HATCO AUTHORIZED PARTS DISTRIBUTORS ALABAMA IOWA NEW YORK TEXAS Jones McLeod Appl. Svc. Electric Motor Service Co. Acme American Repairs, Inc. GCS Service Birmingham 205-251-0159 Davenport 319-323-1823 Brooklyn 718-456-6544 Fort Worth 800-433-1804 Goodwin Tucker Group Alpro Service Co.
