Page 2
DASH DISASSEMBLY 1. Remove (16) 5mm Allen screws securing (4) screws (4) screws (4) screws (4) screws the dashboard trim panel. (Figure A) 2. Unclip and remove the dashboard trim panel. (Figure B) 3. Remove (4) 9/32” screws securing the radio.
Page 3
KIT PREPARATION KIT ASSEMBLY From the factory dashboard trim panel: 1. Secure the radio brackets to the radio using screws supplied with the radio. 1. Using either a solder gun or cutting tool, (Figure A) remove the plastic welds holding the 2.
