KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Radio mounting brackets • D) (4) White plastic panel clips • E) (8) 5mm x 12mm Phillips Screws
A
B
Metra. The World's Best Kits.
®
Ram Promaster
*Visit MetraOnline.com for up-to-date vehicle specific applications.
KIT FEATURES
• ISO DDIN radio provision
• Custom texture
C
MetraOnline.com
2014-up*
D
E
© COPYRIGHT 2018 METRA ELECTRONICS CORPORATION
95-6523
I N S TA L L AT I O N I N S T R U C T I O N S
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Assembly ..........................................................3
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: 70-1784 or XSVI-6523-NAV
Antenna Adapter: 40-VW10 or 40-EU10
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• 86-5618 radio removal tool
• 86-3528 radio removal tool
CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
REV. 3/16/18 INST95-6523
