- Page 1 VITAE Infrarot-Strahler Assembly and operating instruction Druck Nr. 29342328en / 27.12...
- Page 2 English Table of Contents Important notice ......................3 Technical data ......................5 Electrical connection ....................5 Assembly .......................6 Assembly example: ...................6 Assembly on the booth wall ................6 vertical assembly in the booth corners ..............6 Minimum distances ...................6 Service Address: .....................7 Guarantee .......................7 Handling procedures for return shipments (RMA) - Details for all returns ! ....8...
- Page 3 English Important notice There is a fi re risk if assembled incorrect- ly. Please read these assembly instruc- Dear Customer, tions carefully. Take special note of the measurement details and the following You have purchased a high quality technical notes. system which will provide you with many ye- ars of enjoyable using.
- Page 4 • The assembly of the infrared emitter in Although breakage is unlikely if it the booth must be carried out in such a is used properly, if the ceramic way to assure even all-round emission emitter should break, replace it with a for the sauna frequenter.
- Page 5 Weight: approx. 2 kg distribution controllert Power Vitae 350 W, Art.-Nr. 94.2865 input: Vitae 500 W, Art.-Nr. 94.2576 Vitae 750 W, Art.-Nr. 94.2577 emission area: 1,4 mm - 10 mm measures HWD: 900 x 184 x 65 mm...
- Page 6 4 cm (Fig.6). Caution! For assembly of the net emitter, the IR-Emitter Vitae measurements specifi ed in Fig. 5 must be complied with. Very important! In the case of vertical assembly (connec- tion always upwards or in accordance with the booth manufacturer‘s specifi...
- Page 7 Service Address: Outside of Germany please contact your EOS Saunatechnik GmbH specialist dealer in case of warranty claims. Adolf-Weiß-Straße 43 Direct warranty processing with our service 35759 Driedorf-Mademühlen, Germany department is in this case not possible.
- Page 8 Handling procedures for return shipments (RMA) - Details for all returns ! Dear customer we hope that you will rejoice in the ordered articles. Just in case that you are not entirely contented as an exeption, please follow the procedures specifi ed below.This enabling us to ensure a quick and smooth handling of the return shipment.
