- Page 1 Assembly instructions and instructions for use Infrarot-Strahler VITAE Druck Nr. 29342328en / 33.06...
-
Page 2: Important Notice
Weight: approx. 2 kg Ensure that this hot convection air can escape by Power Vitae 350 W, Art.-Nr. 94.2865 rising freely. input: Vitae 500 W, Art.-Nr. 94.2576 Vitae 750 W, Art.-Nr. 94.2577 If necessary, appropriate steps should be taken (e.g. - Page 3 Caution! Remove the transport stabilisers from the Vitae- Fig 4 emitter, loosening the covering grille. Remove the foamed pad. Take care that the Vitae-emitter does not be demaged. Mounting example in the sauna cabin with Remove the protect additional upper bench.
-
Page 4: Electrical Connection
Recommended distance between human and emitter Very important! is approx. 50 cm (see fig. 6). In the case of vertical assembly (connection always upwards or in accordance with the booth manufacturer's specifications), the area above the emitter should not be encased with wood in front (Fig. - Page 5 The IR-emitter is designed for mounting in a IR-warm cabin or sauna only. It just can be used with a controller. The warranty is not to apply for other use. Vitae lamp Service address: EOS-Werke Günther GmbH Adolf-Weiß-Str. 43...
