Gator G42V User Manual

Wide angle 2-in-1 reversing camera/brake light solution with wireless controller

Advertisement

Quick Links

U s e r M a n u a l
G42V
PRODUCT FEATURES:
- Resolution
- Picture Mode
- CMOS Chipset:
- Lens FOV:
- Viewing Angles:
- Waterproof Rating:
- Parking Guidelines

Prior to Installation

Read the manual prior to installation. Technical knowledge is necessary for installation. Please ensure you use
the correct tools to avoid damage to the vehicle or product.
Aerpro can not be held responsible for the installation of this product.
Technical Support
TDJ want to provide a fast and suitable resolution should you encounter any technical issues. With this in mind,
when contacting TDJ, try to provide as much information as possible. This will speed up the process and help us
to help you.
Please visit gatordriverassist.com/contact
Wide Angle Universal Brake Light Camera
2-in-1 Reversing Camera/Brake Light Solution
with Wireless Controller
720 x 480 (Wide Angle View)
NTSC
1/3"
210 Degrees (H) x 140 Degrees (V)
Birds-Eye, Wide Angle, Reversing Left/Right Blind Spot, Driving
IP67
Yes (Removable/Dynamic)
Connects2Vision
V1-10-19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G42V and is the answer not in the manual?

Questions and answers

Summary of Contents for Gator G42V

  • Page 1 V1-10-19 Connects2Vision U s e r M a n u a l G42V Wide Angle Universal Brake Light Camera 2-in-1 Reversing Camera/Brake Light Solution with Wireless Controller PRODUCT FEATURES: - Resolution 720 x 480 (Wide Angle View) - Picture Mode...
  • Page 2 Connects2Vision INSTALLATION Wiring Diagram Camera replaces OEM brake light Power Adapter Cable CAM-42 Make Connections to Vehicle/Unit Wireless Controller (Mount on dashboard) Extension Cable Control Unit Acc 12V Connect to vehicle 12V Accessory feed Black Ground Connect to ground Green Reverse Trigger Connect to vehicle reverse trigger output Blue...
  • Page 3 Connects2Vision Connecting CAN-Bus Wiring Locate the vehicle’s OBD port and unscrew/ remove the female connector. On the reverse of the connector (the side where wiring enters it), connect the CAN + (blue) and CAN - (white) wires from the harness to the locations specified in the diagram (Pins 1 and 9).
  • Page 4 Connects2Vision Wide Angle Right Blind Spot (Select from HUD Menu) (Triggered by Indicator - See Page 4) Birds-Eye Left Blind Spot (Select from HUD Menu) (Triggered by Indicator - See Page 4) Adjusting Settings To adjust settings for all viewing modes, press A from the HUD menu to enter the settings menu. Once in the settings menu, short press A to cycle through the various settings screens available.
