Summary of Contents for Gator GX5HDKT
- Page 1 5HDKT 5” Monitor Reversing camera “ “ 5” NTSC Surface/Suction Trailer & Parking Screen Size Auto Switch Voltage Mounts Guide Lines ABC-123 IP67 Number Plate Wired IP67 Rating Noise Filter Wide Angle Wide Angle Mount PAGE 1 GX5HDKT INSTRUCTION MANUAL...
-
Page 2: Introduction
INTRODUCTION WELCOME Thank you for purchasing the Gator GX5HDKT 5” Monitor + Reverse Camera. Please ensure that you have read the product manual and instructions in full, prior to installation and use. Failure to do so may result in product failure/damage or incorrect operation and therefore impact the product performance. -
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION.................PAGE: 2 PRODUCT FEATURES..............PAGE: 2 PACKAGE COMPONENTS............PAGE: 2 INSTALLING THE MONITOR.............PAGE: 4 INSTALLING THE CAMERA............PAGE:5-6 TESTING THE REVERSE CAMERA FUNCTION......PAGE:6 MENU FUNCTIONS...............PAGE:7 TRAILER/PARKING REVERSING GUIDES.........PAGE:7 PRODUCT SPECIFICATIONS............PAGE:8 TECHNICAL ASSISTANCE............PAGE:8 PAGE 3 GX5HDKT INSTRUCTION MANUAL... -
Page 4: Installation Diagram
Earth Earth Earth Earth 0.5 Metres 0.5 Metres CANBUS Filter (Red Camera Power Reversing light) (Red Camera Power Reversing light) (NOTE: This con guration is used for CANBUS vehicles to lter unwanted video noise. ) PAGE 4 GX5HDKT INSTRUCTION MANUAL... -
Page 5: Installing The Camera
(through a rubber grommet) and seal the hole with silicone to avoid water leakage. 4.Refit the license plate over the camera bracket using the original bolts/screws. PAGE 5 GX5HDKT INSTRUCTION MANUAL... - Page 6 1.Engage the park brake and turn the ignition key to the on position. DO NOT start the vehicle. 2. Select reverse gear with the gear shift. The monitor will sense the video signal from the camera automatically and will display the camera’s image of the rear of the vehicle. PAGE 6 GX5HDKT INSTRUCTION MANUAL...
-
Page 7: Menu Functions
- Reset: Resets all menu setting back to factory configuration (Press + or - to confirm) GUIDE LINES There are 2 types of guide lines, Trailer Hook UP and Parking. Trailer Hook Up Mode 1 Parking Mode 2 Fig.1 PAGE 7 GX5HDKT INSTRUCTION MANUAL... -
Page 8: Product Specifications
- Dimensions (Camera Only): 15mm(H) x 15mm(W) x 21mm(D) - Dimensions (Camera & Bracket): 40mm(H) x 365mm(W) x 35mm(D) TECHNICAL ASSISTANCE If you need assistance setting up or using your Gator product now or in the future, call Gator Support. Australia TEL: 03 – 8587 8898 FAX: 03 –...
