Condumax CLS15D/16D/21D
The Dipfit CLA111 immersion assembly is available for installing sensors with G1 thread in
vessels.
 7
Installation in Dipfit CLA111 immersion assembly, fastening versions A, B and D
Ensure that the electrodes are fully immersed in the medium during measurement.
4.2

Post-installation check

1.
Are the sensor and cable undamaged?
2.
Is the sensor installed in the process connection and is not suspended from the cable?
5

Electrical connection

WARNING
L
Device is live!
Incorrect connection may result in injury or death!
The electrical connection may be performed only by an electrical technician.
The electrical technician must have read and understood these Operating Instructions and
must follow the instructions contained therein.
Prior to commencing connection work, ensure that no voltage is present on any cable.
Endress+Hauser
A
B
Electrical connection
D
A0024145
