Installation
1
1
With NPT ½" thread in T-piece or cross
fitting
1
T-piece or cross fitting (DN 32, 40 or 50)
2
Glue-in VC threaded coupling (NPT ½" for
DN 20)
3
Glue-in adapter coupling (for DN 32, 40, 50)
1.
Ensure that the electrodes are fully immersed in the medium during measurement.
Immersion depth: at least 35 mm (1.38").
2.
If using the sensor in the ultrapure water range, you must work under air-evacuated
conditions.
Otherwise, the CO
can increase the conductivity by up to 3 µS/cm.
14
2
3
A0019015
in the air can dissolve in the water and its (weak) dissociation
2
1
NPT ½"
38.5
(1.52)
2
Ø 6 (0.24)
Ø 29 (1.14)
2
With NPT ½" thread in flow assembly
71042405, dimensions in mm (inch)
1
Sensor holder NPT ½"
2
Inlet
3
Outlet
Condumax CLS15D/16D/21D
3
A0019014
