8. Remove pivot screw from top hinge, invert screw and reinstall
pivot screw in top hinge. See Figure 19.
RIGHT SIDE
DOOR SWING
PLASTIC
PLUG
HOLE
9. Remove three plastic screw
plugs in hinge holes, top of
cabinet, opposite side. Be
careful not to scratch cabi-
net (see Figure 22).
Figure 22
10. Place door on lower hinge
pin. Invert and install upper
hinge on door.
HINGE
SCREW
RIGHT SIDE INVERT
HINGE SCREW
Figure 21
UL114A
INVERT
HINGE
11. Fasten upper hinge to unit (3
screws).
screws until door is aligned.
See Figure 23.
Figure 23
15
LEFT SIDE
DOOR SWING
PLASTIC
PLUG
HOLE
UL115
Partially tighten
UL119
