GLASS SHELF INSTALLATION

(FOR MODELS WITH GLASS SHELVES)
1. Carefully remove the shelves from inside the unit and remove the
packaging.
2. Slide the shelves onto desired ribs, making sure that the silver
edge strip is toward the front of the unit and the decorative graph-
ics are on the underside of the shelves. Make sure the shelves are
inserted fully into the unit (see Figure 14). The white edge strip
towards the rear (Models 15R, 29R and 75R only) prevents cans
and bottles from freezing against the cold evaporator.
Be sure to place shelves with the silver edge to the front
and decorative graphics on the underside.
Figure 14
NOTE
