Compound Mitre Saw – CM-210
User Manual
[Revision 2.0 February 2020]
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE
AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may
E&OE
© 2020 Baumr-AG
vary in appearance, assembly, inclusions, specifications, description and packaging.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CM-210 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Baumr-AG CM-210

Summary of Contents for Baumr-AG CM-210

  • Page 1 Compound Mitre Saw – CM-210 User Manual [Revision 2.0 February 2020] READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may E&OE...

  • Page 2: Safety

    Compound Mitre Saw – CM-210 Safety Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or equipment or property damage if not understood or followed. Safety messages have the following symbols: You WILL be KILLED or...
  • Page 3 Compound Mitre Saw – CM-210 General Electrical Safety General Electrical Safety General Service Information • Inspect electrical equipment, extension • Electrically grounded equipment must have • The equipment must be serviced or cords, power bars, and electrical fittings for an approved cord and plug and be repaired at authorised service centres by damage or wear before each use.
  • Page 4 Compound Mitre Saw – CM-210 • Contact with the saw blade in the uncovered saw zone. • Reaching into the running saw blade (cut injuries). • Kick-back of workpieces and parts of workpieces. • Saw blade fracturing. • Catapulting of faulty carbide tips from the saw blade.
  • Page 5 Compound Mitre Saw – CM-210 • Carefully maintain power tools and accessories. Check moving parts for proper function and smooth running, and check whether there are parts which are broken or damaged to the extent that the functionality of the power tool is impaired.
  • Page 6 Compound Mitre Saw – CM-210 • Do not use saw blades made of high speed steel. • Check the condition of the saw blades before using the crosscut, drag and mitre saw. • Make sure that a suitable saw blade for the material to be cut is selected.

  • Page 7: Safety Symbols

    Compound Mitre Saw – CM-210 Safety Symbols The product may have safety warning labels attached to it, explained below. Understand the symbols on your product and their meanings. If any stickers become unreadable, unattached etc., replace them. Flammable Material Hazard...
  • Page 8 Compound Mitre Saw – CM-210 Carbon-Monoxide Hazard Pull Hazard Slope / Fall Injury Hazard "Slam Dunk" Warning Do not use the product in Be aware that the product Be aware that using the product Do NOT attempt "slam dunk" confined areas or without...

  • Page 9: Table Of Contents

    Compound Mitre Saw – CM-210 Table of Contents Safety ................................2 Safety Symbols ................................7 Parts Identification ............................. 10 Before Starting the Equipment ........................15 Checking the Moving Saw Blade Guard Safety Device ................... 15 Attachment and Operation ......................... 16 Attaching the Mitre Saw ............................

  • Page 10: Parts Identification

    Compound Mitre Saw – CM-210 Parts Identification Name Name Name Handle Scale Stop for cutting depth limiting ON/OFF switch Rotary table Adjusting screw (90°) Lock switch Fixed saw table Adjusting screw (45°) Machine head Stop rail Flange screw 16a. Movable stop rail...
  • Page 11 Compound Mitre Saw – CM-210 E&OE © 2020 Baumr-AG...
  • Page 12 Compound Mitre Saw – CM-210 E&OE © 2020 Baumr-AG...
  • Page 13 Compound Mitre Saw – CM-210 E&OE © 2020 Baumr-AG...
  • Page 14 Compound Mitre Saw – CM-210 E&OE © 2020 Baumr-AG...

  • Page 15: Before Starting The Equipment

    Compound Mitre Saw – CM-210 Before Starting the Equipment ATTENTION! The device and packaging materials are not toys! Children must not be allowed to play with plastic bags, film and small parts! There is a risk of swallowing and suffocation! •...

  • Page 16: Attachment And Operation

    Compound Mitre Saw – CM-210 Attachment and Operation Attaching the Mitre Saw E&OE © 2020 Baumr-AG...
  • Page 17 Compound Mitre Saw – CM-210 1. In order to adjust the rotary table (13), loosen the set screw (10) approximately 2 turns. 2. Turn the rotary table (13) and pointer (11) to the desired angle measurement on the scale (12) and use the set screw (10) to secure it.

  • Page 18: Precision Adjustment Of The Stop For Crosscut 90

    Compound Mitre Saw – CM-210 Precision Adjustment of The Stop for Crosscut 90° E&OE © 2020 Baumr-AG...
  • Page 19 Compound Mitre Saw – CM-210 No stop angle included. 1. Lower the machine head (4) and secure it using the locking bolt (21). 2. Loosen the set screw (20). 3. Position the angle stop (A) between the saw blade (6) and the rotary table (13).
  • Page 20 Compound Mitre Saw – CM-210 Crosscut 90° and Turntable 0° E&OE © 2020 Baumr-AG...
  • Page 21 Compound Mitre Saw – CM-210 Attention! For 90° crosscuts, the moveable stop rail (16a) must be fixed in the inner position. 1. Open the set screw (16b) for the moveable stop rail (16a) and push the moveable stop rail (16a) inwards.

  • Page 22: Crosscut 90° And Turntable 0

    Compound Mitre Saw – CM-210 Crosscut 90° and Turntable 0° - 45° E&OE © 2020 Baumr-AG...

  • Page 23: Precision Adjustment Of The Stop For Mitre Cut 45

    Compound Mitre Saw – CM-210 The mitre saw can be used to make crosscuts of 0° -45° to the left and 0° -45° to the right in relation to the stop rail. Important! For 90° crosscuts, the moveable stop rail (16a) must be fixed in the inner position.
  • Page 24 Compound Mitre Saw – CM-210 No stop angle included. 1. Lower the machine head (4) and secure it using the locking bolt (21). 2. Fix the rotary table (13) in the 0° position. Attention! For mitre cuts (inclined saw head), the moveable stop rails (16a) must be fixed in the outer position.
  • Page 25 Compound Mitre Saw – CM-210 Mitre Cut 0°- 45° and Turntable 0° E&OE © 2020 Baumr-AG...

  • Page 26: Mitre Cut 0°- 45° And Turntable 0

    Compound Mitre Saw – CM-210 The mitre saw can be used to make mitre cuts of 0° - 45° in relation to the work face. Attention! For mitre cuts (inclined saw head), the moveable stop rails (16a) must be fixed in the outer position.

  • Page 27: Limiting The Cutting Depth

    Compound Mitre Saw – CM-210 The mitre saw can be used to make mitre cuts to the left of 0°- 45° in relation to the work face and, at the same time, 0° - 45° to the left or 0° - 45° to the right in relation to the stop rail (double mitre cut).

  • Page 28: Sawdust Bag

    Compound Mitre Saw – CM-210 Sawdust Bag The saw is equipped with a debris bag (17) for sawdust and chips. 1. Squeeze together the metal ring on the dust bag and attach it to the outlet opening in the motor area.

  • Page 29: Changing The Saw Blade

    Compound Mitre Saw – CM-210 Changing the Saw Blade E&OE © 2020 Baumr-AG...
  • Page 30 Compound Mitre Saw – CM-210 Remove the power plug! Important! Wear safety gloves when changing the saw blade. Risk of injury! 1. Swing the machine head (4) upwards and lock with the locking bolt (21). 2. Loosen the retaining screw (5a) of the cover using a Philips screwdriver.

  • Page 31: Using The Laser

    Compound Mitre Saw – CM-210 13. Before continuing your work, make sure that all safety devices are in good working condition. Important! Every time that you change the saw blade (6), check to see that it spins freely in the table insert (9) in both perpendicular and 45°...

  • Page 32: Transport

    Compound Mitre Saw – CM-210 Transport 1. Tighten the set screw (10) to lock the rotary table. 2. Press the machine head (4) downwards and secure with the locking bolt (21). 3. Carry the equipment by the fixed saw table (14).

  • Page 33: Storage

    Compound Mitre Saw – CM-210 Storage • Store the device and its accessories in a dark, dry and frost-proof place that is inaccessible to children. The optimum storage temperature is between 5 and 30˚C. • Store the electrical tool in its original packaging.

  • Page 34: Specifications

    Compound Mitre Saw – CM-210 Specifications Rated power 1700W No-load speed 4900 rpm Blade diameter 210mm (8 inches) Blade teeth Swivel range ± 45° Bevel tilt range 0° - 45° to the left Saw width at 90°: 115 x 60mm Cutting Capacity Saw width at 45°: 115 x 25mm...
  • Page 35 ©2020 Baumr-AG. All rights reserved. No part of this document, including descriptive content, concepts, ideas, diagrams or images may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, scanning or recording, or any information storage and retrieval system,...
