Bandsaw - BS30
User Manual
[Revision 1.0 May 2017]
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY
DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by
this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
E&OE
© 2017 Baumr-AG
Advertisement
Table of Contents
Related Manuals for Baumr-AG BS30
Summary of Contents for Baumr-AG BS30
-
Page 1: User Manual
Bandsaw - BS30 User Manual [Revision 1.0 May 2017] READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance, assembly, inclusions, specifications, description and packaging. -
Page 2: Safety
Bandsaw - BS30 Safety Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or equipment or property damage if not understood or followed. Safety messages have the following symbols: You WILL be KILLED or... - Page 3 Bandsaw - BS30 General Service Information • Have the equipment serviced or repaired at authorized service centres by qualified personnel only. • Replacement parts must be original equipment manufacturer (OEM) to help ensure that equipment safety is maintained. • Do not attempt any maintenance or repair work not described in this instruction manual.
-
Page 4: Table Of Contents
Bandsaw - BS30 Table of Contents Safety ............................. 2 Parts Identification ........................5 Machine Components ..........................6 Assembly and Set-Up ........................7 Blade Tension .............................. 7 Blade and Roller Alignment .......................... 7 Setting the Blade Guide and Counter-Pressure Bearings ................8 Install and Level the Table ........................... -
Page 5: Parts Identification
Bandsaw - BS30 Parts Identification Name Name Bandsaw Tools / Fasteners: 3mm Allen Key Table 6mm Allen Key Fence Spanner 4 M6x15 Screw Protractor Pusher E&OE © 2017 Baumr-AG... -
Page 6: Machine Components
Bandsaw - BS30 Machine Components Name Name Machine Body Blade Tension Adjustor Table Table Angle Adjustor Blade Table Stop Screw Blade Guide ON / OFF Switch Motor Lamp Switch Lamp Upper Door Lower Door Dust Port Roller Adjustor Pusher Hanger E&OE... -
Page 7: Assembly And Set-Up
Bandsaw - BS30 Assembly and Set-Up It is recommended that the machine is bolted to a suitable flat and level surface. Use the 4 mounting holes on the machine base and M8 (3/8") fasteners (not supplied) to secure it. • The machine is for indoor use only. -
Page 8: Setting The Blade Guide And Counter-Pressure Bearings
Bandsaw - BS30 Setting the Blade Guide and Counter-Pressure Bearings The machine has a blade guide to help keep the blade from deflecting sideways during cutting and 2 "counter-pressure" bearings that support the back edge of the blade and prevent it deflecting from the cutting pressure (that is, how much you push the work-piece against the blade during cutting). -
Page 9: Install And Level The Table
Bandsaw - BS30 Install and Level the Table 1. Set the table angle adjustor (M) to 30°, then tighten the thumbscrew (N) by hand. 2. Carefully slide the table (1) into position and align the mounting holes on the underside of the table with the holes in the table angle adjustor. -
Page 10: Operation
Bandsaw - BS30 Operation Risk of injury when operating the machine. Always use caution when handling the workpiece. Use the "pusher" whenever possible. • Health risks may be present from the inhalation of sawdust. Wear a respirator. A dust extraction system is recommended. • Ensure that the blade before using the machine. -
Page 11: Using The "Fence
Bandsaw - BS30 Using the "Fence" Use the "fence" to act as a work-piece guide for ripping lengths of wood, cutting many pieces to the same length etc. 1. Hook the prong (I) on the end of the fence (G) over the end of the table (H). -
Page 12: General Operational Recommendations
Bandsaw - BS30 General Operational Recommendations The following recommendation are a guide to improved safety as well as machine care. Not all recommendations can be applied to every task – caution and common-sense must also be applied to using the machine. -
Page 13: Maintenance
Bandsaw - BS30 Maintenance Ensure the machine is switched OFF and disconnected from the electrical supply before performing any maintenance tasks. • All protection and safety devices must be immediately re-installed once the maintenance work is completed. • Some maintenance activities described may be beyond the scope of some users. -
Page 14: Troubleshooting
Bandsaw - BS30 Troubleshooting The following information may assist in identifying a problem and rectifying it. Saw blade breaks. Possible Fault Action Too much blade tension Reduce blade tension. Saw blade coming off rollers. Possible Fault Action Blade and rollers not aligned correctly Set blade and roller alignment. -
Page 15: Specifications
Bandsaw - BS30 Saw Blade Overheating or Work-Piece Burning Possible Fault Action Fence not parallel Ensure the fence (if used) is parallel to the blade. Cut straight. Saw blade blunt Replace saw blade. Incorrect saw blade type Use correct type of saw blade for material. - Page 16 ©2017 Baumr-AG. All rights reserved. No part of this document, including descriptive content, concepts, ideas, diagrams or images may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, scanning or recording, or any information storage and retrieval system, without express permission or consent from the publisher.
