- Page 1 Concrete Saw User Manual RETAIN THIS MANUAL FOR FUTURE REFERENCE PLEASE READ THIS MANUAL CAREFULLY BEFORE USE Click to Watch: Starting a 4-Stroke...
-
Page 2: Table Of Contents
Concrete Saw Table of Contents Safety ................................. 1 Operation ................................2 Front Pointer Alignment ..........................2 Adjusting Depth of Cut Gauge ........................2 Quick Start Guide ............................3 When Finished .............................. 4 Maintenance ..............................4 Spark Plug ..............................4 Air Filter................................. 5 Oil ................................. -
Page 3: Safety
Concrete Saw Safety • DO NOT operate or service this equipment before reading the entire manual． • This equipment should not be operated by persons under 18 years of age． • NEVER operate this equipment without proper protective clothing, shatterproof glasses, steel- toed boots and other protective devices required by the job．... -
Page 4: Operation
Concrete Saw Operation Front Pointer Alignment The pointer should be checked for proper alignment with the blade after every use. Mark a 4 feet long straight line on With the blade parallel to the line, Adjust the pointer in or out if the a smooth level surface. -
Page 5: Quick Start Guide
Concrete Saw Quick Start Guide Step 1: Remove oil dipstick (or cap) and ensure Step 5: Pull starter cord until it kicks (About enough engine oil (10W30 recommended 3-4 times, more if cold weather) 600ML) Step 2: Locate on/off switch and turn on Step 6: Turn choke on Step 3: Turn fuel lever on and choke to cold Step 7: Pull starter cord until engine starts... -
Page 6: When Finished
Concrete Saw When Finished Step 1: When finished, turn throttle to low Step 2: Switch off engine Step 3: Turn fuel lever off when stored Maintenance Spark Plug 0.6 – 0.7 mm Clean or replace the spark plug as needed to ensure proper operation. Refer to the table below for frequency. -
Page 7: Air Filter
Concrete Saw Air Filter NOTICE: NEVER run the engine without the air cleaner. Severe engine damage will occur. The engine is equipped with a dual-element air cleaner. Under normal operating conditions, the elements should be cleaned once every week. Under severe, dry and dusty conditions, the elements should be maintained daily. - Page 8 Concrete Saw Once drained, fasten the screw plug back in. Refill with 600ml of 10W30 (recommended) engine oil by removing the dipstick (circled in red) and pouring into cavity. Check oil by removing dipstick and wiping it clean. Dip it back into its cavity without fully screwing it back in. LOW –...
-
Page 9: Specifications
Concrete Saw Specifications Engine type 4-Stroke OHV Displacement 196CC Max. Output 7hp/3600rpm Fuel Type Regular Unleaded 95 +RON Fuel Capacity 3.6L Oil Capacity 0.6L Engine Oil Grade SAE 10W 30 Blade Type / Diameter Diamond / 350mm Blade Width Circumferential Speed 2800R/Min Blade Revolution 3600rpm... - Page 10 Some experts believe that the incorrect or prolonged use of almost any product may cause serious injury or death. To help reduce your risk of serious injury or death, refer to the information below. For more information, see www.datastreamserver.com/safety ...
