20V Cordless Circular Saw CS2
User Manual
[Revision 1.0 August 2017]
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY
DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by
this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
E&OE
© 2017 Bäumr-AG
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Baumr-AG CS2
Summary of Contents for Baumr-AG CS2
- Page 1 20V Cordless Circular Saw CS2 User Manual [Revision 1.0 August 2017] READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
-
Page 2: Safety
20V Cordless Circular Saw CS2 Safety Read and understand all safety warnings before using the tool. • Avoid dangerous environments. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite dust or fumes. - Page 3 20V Cordless Circular Saw CS2 • When restarting the tool with the blade in the work-piece, centre the blade in the cut and check that the teeth are not engaging the material. • Support large work-pieces to minimize the risk of blade pinching and kick-back. Large work-pieces tend to sag under its own weight.
- Page 4 20V Cordless Circular Saw CS2 • Do not touch the battery terminals with metal objects and/or body parts as short-circuit and/or personal injury may result. • Explosion hazard – protect the battery against heat; for example, direct sunlight and fire.
-
Page 5: Table Of Contents
20V Cordless Circular Saw CS2 Table of Contents Safety ..............................2 Parts Identification ..........................6 Batteries and Battery Charging ......................7 Charging ..............................7 Inserting and Removing the Battery Pack ....................7 Operation ............................8 Setting Cutting Depth ..........................8 Setting Bevel Angle ............................ -
Page 6: Parts Identification
20V Cordless Circular Saw CS2 Parts Identification Name Name Tool Body Bevel Guide Lock Nut Main Handle Laser Guide Secondary Handle Laser Guide ON / OFF Switch Base Plate Blade Collar / Lock Bolt Blade Dust Port Lower Blade Guard... -
Page 7: Batteries And Battery Charging
20V Cordless Circular Saw CS2 Batteries and Battery Charging Batteries for this tool are supplied in a low-charge condition for shipping reasons. • A battery that is new or has not been used for a long period does not charge to full capacity until after approximately 5 charge/discharge cycles. -
Page 8: Operation
20V Cordless Circular Saw CS2 Operation Setting Cutting Depth Saw cutting depth can be set anywhere in the range of 0 to 50mm. Remove the battery from the tool. Loosen (rotate left) the depth guide lock nut (A). Hold the tool by the handle, then rotate the rear of the base plate (B) downward to reduce cutting depth. -
Page 9: Using The Rip Fence
20V Cordless Circular Saw CS2 Using the Rip Fence The "rip fence" is used to keep the cut parallel to the edge of the material being cut for the length of the material (known as "ripping"), or for cutting multiple pieces of the same (approximate) width without marking out each cut. -
Page 10: Cutting
20V Cordless Circular Saw CS2 Cutting Fully understand all operational safety warnings before using the tool. 1. Secure the work-piece and ensure nothing is directly below the cut line. 2. Bring the tool up to the work-piece so the front of the base plate is resting on it, but not so that the blade is touching the work-piece. -
Page 11: Maintenance And Troubleshooting
20V Cordless Circular Saw CS2 Maintenance and Troubleshooting Remove the battery from the tool before performing any maintenance. • The tool should be cool enough to touch before performing maintenance activities. • Wear suitable gloves when handling blades. • Some maintenance activities described may be beyond the scope of some users. For procedures that you are not comfortable with or have the tools or experience for, have the unit serviced by a service centre or qualified technician. -
Page 12: Troubleshooting
20V Cordless Circular Saw CS2 8. Clean all parts, including the spindle area of the tool of any sawdust or wood particles etc – it is essential that this area is clean, so when the new blade is installed it will run true. -
Page 13: Specifications
20V Cordless Circular Saw CS2 Excessive vibration. Possible Fault Action Replace blade. Blade dull, bent or damaged Specifications Battery Charger Electrical Requirements 240VAC / 50Hz Battery Type 20V Lithium-Ion Cutting Speed 3800 RPM (no load) Saw Blade 165mm / 20mm bore Maximum Cut Depth 52mm @ 0°... - Page 14 20V Cordless Circular Saw CS2 Some experts believe the incorrect or prolonged use of almost any product could cause serious injury or death. For information that may reduce your risk of serious injury or death, consult the points below and additionally, the information available at www.datastreamserver.com/safety •...
