Scroll Saw - SS16

User Manual

[Revision 1.0 May 2017]
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY
DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by
this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
E&OE
© 2017 Baumr-AG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SS16 and is the answer not in the manual?

Questions and answers

Related Manuals for Baumr-AG SS16

Summary of Contents for Baumr-AG SS16

  • Page 1: User Manual

    Scroll Saw - SS16 User Manual [Revision 1.0 May 2017] READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.

  • Page 2: Safety

    Scroll Saw - SS16 Safety Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or equipment or property damage if not understood or followed. Safety messages have the following symbols: You WILL be KILLED or...
  • Page 3 Scroll Saw - SS16 Product Use and Care Electrical Information General Service Information • • • Use supplied or recommended Electrocution / shock hazard - The Have the equipment serviced or accessories only. Follow the machine MUST be connected to a...

  • Page 4: Table Of Contents

    Scroll Saw - SS16 Table of Contents Safety ............................. 2 Parts Identification ........................5 Assembly and Set-Up ........................6 Mounting the Machine to a Workbench ....................... 6 Align the Bevel Indicator ..........................7 Blade Guard Foot Adjustment ........................7 Dust Blower Adjustment ..........................7 Sawdust Collection Port ..........................

  • Page 5: Parts Identification

    Scroll Saw - SS16 Parts Identification Letter Name Blade Tension Knob Arm Housing Rubber Bearing Covers Table Sawdust Blower Storage Area Base Bevel Scale and Pointer Table/Bevel Lock Knob Lower Blade Holder Blade Guard Foot Blade Guard Foot Lock Knob...

  • Page 6: Assembly And Set-Up

    Scroll Saw - SS16 Assembly and Set-Up Do not attempt to modify the product or use accessories not supplied or recommended for use with this tool. Any such alteration or modification may result in hazards leading to possible serious personal injury and will void any warranty. • Do not connect the machine to an electrical supply until assembly is complete.

  • Page 7: Align The Bevel Indicator

    Scroll Saw - SS16 Align the Bevel Indicator The bevel indicator has been factory adjusted, however, should be checked prior to use (Fig. 3 to 6). 1. Remove the blade guard foot (1) using the Phillips screwdriver (2) to loosen the screw.

  • Page 8: Sawdust Collection Port

    Scroll Saw - SS16 Sawdust Collection Port (Fig. 10 and 11) This scroll saw allows a hose or vacuum accessory (not supplied) to be connected to the dust port (1). If excessive sawdust build up occurs inside the base, use a vacuum cleaner or manually remove sawdust by removing the screws (2) and metal plate on the left side of the saw.

  • Page 9: Operation

    Scroll Saw - SS16 Operation Risk of injury when operating the machine. Always use caution when handling the work- piece. • Risk of injury when handling saw blades. Use caution and wear protective gloves. • Ensure that the blade is correctly installed and adjusted before using the machine. • Do NOT attempt to cut materials that are not suitable to the cutting speed of the machine and blade type.

  • Page 10: Power Switch And Speed Control

    Scroll Saw - SS16 Power Switch and Speed Control To avoid injury from accidental start-ups, always switch the machine OFF and disconnect it from the electrical supply before moving it, replacing the blade, or making adjustments. • Always wait for the saw to come to a complete stop before restarting.

  • Page 11: Interior Cutting

    Scroll Saw - SS16 Interior Cutting (Fig. 19) 1. Drill a 6mm (1/4") or larger hole in the work-piece. 2. Remove the blade from the machine. 3. Place the work-piece on the table, with the hole in it over the access hole in the table.

  • Page 12: Maintenance

    Scroll Saw - SS16 Maintenance Ensure the machine is switched OFF and disconnected from the electrical supply before performing any maintenance tasks. • All protection and safety devices must be immediately re-installed once the maintenance work is completed. • When servicing, use only identical replacement parts.

  • Page 13: Plain Blades

    Scroll Saw - SS16 Plain Blades 1. Remove the table insert (1) – carefully pry up on the insert to lift it from the table, then rotate and pull it from the machine. 2. Loosen the tension on the blade by rotating the blade tension knob (2) left (anti-clockwise) until no tension remains on the blade.

  • Page 14: Specifications

    Scroll Saw - SS16 Specifications Electrical Requirements 240VAC / 50Hz, 0.8A Speed 550 to 1600 SPM Throat Depth 406mm (16") Blade 5" pin-end and plain Blade Stroke 14mm (9/16") Cutting Capacity 50mm (2") at 90° Table Tilt 0° to 45°...
