ceiling sensor installation
The ideal location for the ceiling sensor is in the center of the ceiling. This will provide a clear signal path
for the IR transmission from the transmitter to the dome sensor without obstruction. In addition, you will
have 360º coverage and will minimize the transmission distance for more reliable performance.
Installation 1 - Attach to T-bar Rail
Installation 2 - Attach to wood surface
Installation 3 - Attach to drywall or concrete
surface
12
