Wiring Diagram - TeachLogic Matrix Installer And Operation Manual

wiring diagram

CEILING/WALL MOUNT SPEAKERS
From page system
THIRD PARTY 3RD PARTY INTERCOM/
INTERCOM/PAGING PAGING SYSTEM WALL
SPEAKER PANEL
Emergency
Normal
Wall mounted
call button
UP TO 2 MEDIA DEVICES
CEILING SENSOR(S)
CPS-120/CPR-125
CONTROL PANEL
Output to front o ce
intercom panel via
existing intercom cabling
LESSON CAPTURE
RECORDER
REMOTE
ASSISTIVE LISTENING
DEVICE (3.5 mm
analog output)
8
