Sanyo FXD-770GD Service Manual page 34

Full panel detachable high power fm/am stereo receiver compact disc player
Hide thumbs

Advertisement

Ref. No.
Part No.
R125
TK165333106
R127
TK165322406
R128
TK165318306
R129
TK169162210
R131
TK165315306
R132
TK165382106
R134
TK165318206
R135
TK165333306
R136
TK165356206
R138
TK165347206
R139
TK165368306
R140
TK165310506
R141
TK165347306
R146
TK165322106
R155
TK165318106
R156
TK169162010
R161, R171
TK165300006
R191
TK165300006
TK182522710
TK21235240
RF33 CIRCUIT BOARD FOR FXD-775RDS
Description
RESISTOR, CHIP, 330OHM 1/16W
RESISTOR, CHIP, 220KOHM 1/16W
RESISTOR, CHIP, 18KOHM 1/16W
RESISTOR, SEMI-FIXED, KVSF637A-473B
RESISTOR, CHIP, 15KOHM 1/16W
RESISTOR, CHIP, 820OHM 1/16W
RESISTOR, CHIP, 1.8KOHM 1/16W
RESISTOR, CHIP, 33KOHM 1/16W
RESISTOR, CHIP, 5.6KOHM 1/16W
RESISTOR, CHIP, 4.7KOHM 1/16W
RESISTOR, CHIP, 68KOHM 1/16W
RESISTOR, CHIP, 1MOHM 1/16W
RESISTOR, CHIP, 47KOHM 1/16W
RESISTOR, CHIP, 220OHM 1/16W
RESISTOR, CHIP, 180OHM 1/16W
RESISTOR, SEMI-FIXED, KVSF637A-223B
RESISTOR, CHIP, 0OHM 1/16W
RESISTOR, CHIP, 0OHM 1/16W
PCB RF33
SHIELD PLATE
— 32 —
