Ref. No.
Part No.
C651, C847
TK157A2230J
C681
TK157C2240J
C701
TK1553106K5
C702, C784
TK157C1040J
C703
TK1552227K6
C709, C785
TK15712200J
C711
TK157A1020J
C760, C891
TK157A1030J
C781
TK15715610J
C782
TK15712210J
C786
TK15712200J
C787
TK157A1050J
C801, C802
TK1552107K6
C806
TK157A5620J
C807
TK15714700J
C808
TK157C1050J
C811
TK15713R00J
C841, C843
TK157A1220J
C842
TK1553107K6
C844, C849
TK157A1220J
C845, C848
TK157A3330J
C846, C852
TK157C1040J
C853, C854
TK157C1040J
C855, C856
TK157C1040J
D551
TK132014800
D552
TK131001801
D553, D661
TK131001901
D611, D683
TK134014611
D621, D631
TK134014511
D641
TK134014511
D662
TK134018111
D663, D672
TK131001901
D671
TK134018121
D701, D702
TK134015041
D703, D704
TK134015041
D705
TK134021931
D706, D707
TK134015041
D708, D709
TK134015041
D720
TK141028200
D781, D801
TK131001901
ET201
TK37303B0
F251
TK176418905
F301
TK175309034
F701
TK175308434
F702
TK176300500
F781
TK1764152B4
IC251
TK112303303
IC301
TK112308400
IC401
TK112311303
MAIN CIRCUIT BOARD FOR FXD-775RDS
Description
CAPACITOR, CHIP, 0.022UF 25V
CAPACITOR, CHIP, 0.22UF 25V
CAPACITOR, ELECTROLYTIC, 10UF 16V
CAPACITOR, CHIP, 0.1U
CAPACITOR, ELECTROLYTIC, 220UF 10V
CAPACITOR, CHIP, 22PF 50V
CAPACITOR, CHIP, 1000PF 50V
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, CHIP, 560PF 50V
CAPACITOR, CHIP, 220PF 50V
CAPACITOR, CHIP, 22PF 50V
CAPACITOR, CHIP, 1UF 10V
CAPACITOR, ELECTROLYTIC, 100UF 10V
CAPACITOR, CHIP, 5600PF 50V
CAPACITOR, CHIP, 47PF 50V
CAPACITOR, CHIP, 1UF 10V
CAPACITOR, CHIP, 3PF 50V
CAPACITOR, CHIP, 1200PF 50V
CAPACITOR, ELECTROLYTIC, 100UF 16V
CAPACITOR, CHIP, 1200PF 50V
CAPACITOR, CHIP, 333 B
CAPACITOR, CHIP, 0.1U
CAPACITOR, CHIP, 0.1U
CAPACITOR, CHIP, 0.1U
DIODE, 1N5401
DIODE, 1SS145T
DIODE, 1SS133T
DIODE, ZENER, MTZJ9.1T-C
DIODE, ZENER, MTZJ5.6T-C
DIODE, ZENER, MTZJ5.6T-C
DIODE, ZENER, MTZJ8.2T-B
DIODE, 1SS133T
DIODE, ZENER, MTZJ8.2T-A-B-C
DIODE, ZENER, MTZJ6.2T-B, C
DIODE, ZENER, MTZJ6.2T-B, C
DIODE, ZENER, MTZJ12T-A, B, C
DIODE, ZENER, MTZJ6.2T-B, C
DIODE, ZENER, MTZJ6.2T-B, C
LED, L-934RS/1ID
DIODE, 1SS133T
BL ASSY RF33R
HQST-3H-07200-10
CERAMIC FILTER, FCR16.93M2GT3-FT
CERAMIC FILTER, FCR5.0MC5T-FT
X'TAL, 32.768KHZ-10PPM
X'TAL, HC-49/U-S4.332M-FT
IC, LC72146M-CT
IC, CXD2587Q
IC, LC75371M-CT
— 23 —
