- Page 1 Control Terminal’s User Manual Control Terminal- TPE100 User Manual UD.6L0201D1989A01...
- Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
- Page 3 LOSS DATA DOCUMENTATION, CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL...
- Page 4 Control Terminal’s User Manual with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
- Page 5 Control Terminal’s User Manual Safety Instruction These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Serious injury or death may be caused if any of these warnings are neglected.
- Page 6 Control Terminal’s User Manual If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center. Cautions: Read the manual carefully before you use the device. ...
- Page 7 Control Terminal’s User Manual unit. Use the device in conjunction with an UPS if possible. Power down the unit before connecting and disconnecting accessories and peripherals. A factory recommended HDD should be used for this device.
-
Page 8: Table Of Contents
Control Terminal’s User Manual Table of Contents Chapter 1 About This Manual ..............8 Chapter 2 Introduction ................9 Product Overview ..................9 Performance ....................9 Specification....................10 Shipping & Storage Requirement............. 11 Chapter 3 Installation ................12 Appearance ....................12 Dimension .................... -
Page 9: Chapter 1 About This Manual
Control Terminal’s User Manual Chapter 1 About This Manual Purpose This document introduces the DS-TPE100 Control Terminal and relevant settings of the product. Intended Audience This document is intended for: Technical support engineers Maintenance engineers... -
Page 10: Chapter 2 Introduction
Chapter 2 Introduction 2.1 Product Overview With the features of low consumption and high performance, DS-TPE100 is designed for entrance/exit control. Adopting the strong aluminum alloy extrusions without fans on its body, the control terminal has a compact structure with good heat dissipation. -
Page 11: Specification
Control Terminal’s User Manual HDMI, with max. resolution and fresh rate of 1920x1080@60Hz Audio: Standard HD, support LINE-IN/LINE-OUT Available interfaces: 2 10/100/1000Mbps Ethernet interfaces, and 4 10M/100Mbps Ethernet interfaces 4 USB2.0 interfaces 2 RS485 interfaces 3 RS232 interfaces ... -
Page 12: Shipping & Storage Requirement
Control Terminal’s User Manual GB9254-2008, radiation disturbance (A), conducted disturbance(A) GB/T17626.2-2006 ESD (2) GB/T17626.4-2008 EFT (2) GB/T17626.5-2008SURGE(2) GB/T17626.6-2008CS (2) GB/T17626.11-2008, auto disconnected when voltage dip, voltage short circuit Reliability: MTBF≥50000h Safety: GB4943 Environmental Suitability: ... -
Page 13: Chapter 3 Installation
Control Terminal’s User Manual Chapter 3 Installation 3.1 Appearance The device appearance is shown below. Figure 3-1 Appearance Dimension Figure 3-2 Dimension... -
Page 14: Interface Description
Control Terminal’s User Manual 3.3 Interface Description Figure 3-3 Interface Introduction Figure 3-4 Interface Description Name Description ALARM OUT 4-ch alarm outputs ALARM IN 2-ch alarm inputs RS-485 2 RS-485 interfaces 2/3/10 RS-232 3 RS-232 interfaces LAN1 4 10/100M Ethernet Interfaces 10/100/1000M Ethernet Interface 100/1000M Ethernet Interface USB Interface... -
Page 15: Assembling Hdd
Control Terminal’s User Manual Name Description DC-12V Power Adapter Interface Grounding 3.4 Assembling HDD Copper Foil Crash Pad Thermal Pad Figure 3-5 Assemble the HDD Assemble the HDD first before you install the HDD to the device. Steps: 1. Align the copper foil to one side of the HDD, and fix the thermal pad to the motor part. -
Page 16: Assembling The Device
Control Terminal’s User Manual 3.5 Assembling the Device Upper Cover Thermal module PCB Board Lower Cover Front Cover Figure 3-6 Main Components Steps: 1. Align the PCB board with the standoffs, and secure the PCB board by tightening the lock screws. 2.
