MOD-6003 QUEEN BED
STEP 6
6.1 Insert and secure the headboard wing (B) to the side rail (E) using hardware parts 1,3 and
8. Repeat the same for other side of side rail.
(Finish step 6, Please screw tied the step 2 bolt & step 5 bolt.)
1
8
1. JCBC BOLT M6 x 45 x 2pcs
STEP 7
7.1 Insert and secure the side rail support (J) to the side rail (E) using hardware parts 1 and
8. Repeat the same for other side of side rail.
1. JCBC BOLT M6 x 45 x 8pcs
x 2
3
SPRING WASHER M6
3.
x 2pcs
J
1
8. ALLEN KEY (BALL SHAPE) M4 x 1pc
8. ALLEN KEY (BALL SHAPE) M4 x 1pc
8
J
06 of 07
