MOD-6003 QUEEN BED
STEP 3
3.1 Insert and secure the headboard support (C) and footboard (D) to the side rail (E) using
hardware parts 2,5,11 and 9. Repeat the same for other side of side rail.
STEP A
STEP B
5
C
E
2
9
11
C
E
L
E
R
D
2. JCBB BOLT M8 x 50 x 8pcs
SPRING WASHER M8
FLAT WASHER M8
9. ALLEN KEY (BALL SHAPE) M5 x 1pc
x 8pcs
x 8pcs
5.
11.
04 of 07
