- Page 1 VEHICLE POSITIONING JACK MODEL NO: VPJ300 PART NO: 7624100 OPERATION AND MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0520 rev 3...
-
Page 2: Specifications
INTRODUCTION Thank you for purchasing this CLARKE Vehicle Positioning Jack. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS GENERAL 1. ALWAYS read and ensure you fully understand the following precautions and the hazards associated with this product. Do not allow anyone who has not read these instructions to use this jack. 2. Only use this jack for its intended purpose. 3. -
Page 4: Servicing & Repairs
DO NOT use. Do not use if an oil leak is apparent. Consult your local dealer. 2. ALWAYS use spare parts supplied by Clarke International. Using non- standard parts could be extremely dangerous. 3. Ensure that the jack is properly maintained at all times and that no corrosion or other damage is allowed to weaken any part of it. - Page 5 OVERVIEW Beam Roller Operating Pedal Locking Pin Pedal Locking Hook Release Valve Thumb Wheel Castor Wheel with Brake UNPACKING During transit or storage, it is possible that an air pocket may have developed within the hydraulic ram, and the ram action may therefore appear to be ‘spongy’.
-
Page 6: Operation
OPERATION WARNING: MAKE SURE THAT THE SAFETY PRECAUTIONS ARE STRICTLY FOLLOWED. NO RESPONSIBILITY CAN BE ACCEPTED FOR INCORRECT USE OF THE JACK Before use, visually inspect the jack for distortion of parts, cracked welds, damaged castors, oil leaks, or any other sign of damage. Should any of these be apparent, have the jack inspected and repaired by a qualified technician before putting back into use. -
Page 7: Cleaning And Maintenance
If the jack has been stored for long periods, check for oil leaks before use and top up via the oil plug on the side of the oil tank if necessary. Oil can be topped up using Clarke Hydraulic Oil, part no. 3050830 for 1 litre, part no. 3050835 for 5 litres). -
Page 8: Parts Diagrams
PARTS DIAGRAMS Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 9: Parts List
PARTS LIST ESCRIPTION UMBER Ram Assembly 29 Secondary O-ring Bolt M16x115mm 30 Grubscrew M10x1,25 Flat Washer 16mm 31 Small Spring Nut M16 32 Steel Ball Roller Guide Block 33 Copper Washer Roller Tube 34 Ram Base Locking Screw 35 Copper Washer Locknut M12 36 N/a Swivel Caster (unbraked) -
Page 10: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 11 USEFUL ITEMS FROM THE CLARKE RANGE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
