Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.
HEAT GUN KIT
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
Model # 2020
bit.ly/wenvideo
(M-F 8AM-5PM CST)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wen 2020
Summary of Contents for Wen 2020
- Page 1 IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.
-
Page 2: Table Of Contents
Specific Safety Rules For Heat Gun Electrical Information Know Your Heat Gun Operation Exploded View and Parts List Warranty TECHNICAL DATA Model number: 2020 Motor: 120 V, 60 Hz, 6.25A/12.5A Wattage: 750W (low), 1500W (high) Cord length: 6 feet Temperature: 572°F... - Page 3 GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFE- TY INSTRUCTIONS. WARNING: To avoid mistakes and serious injury, do not plug in your tool until the following steps have been read and understood.
-
Page 4: Contents Included
GENERAL SAFETY RULES 14. NEVER STAND ON A TOOL. Serious injury could result if the tool tips or is accidentally hit. 15. DO NOT OVERREACH. Keep proper footing and balance at all times. Wear oil-resistant rubber-soled foot- wear. Keep the floor clear of oil, scrap, and other debris. 16. - Page 5 SPECIFIC RULES FOR THE HEAT GUN WARNING: Do not operate the heat gun until you have read and understood the following instruc- tions and the warning labels. 1. DO NOT TOUCH the end of the heat gun during or directly after operation. Let the gun cool down fully before touching the tip or any nozzles.
-
Page 6: Electrical Information
ELECTRICAL INFORMATION IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding provides the path of least resistance for an electric current and reduces the risk of electric shock. This tool is equipped with an electric cord that has an equipment grounding conductor and a grounding plug. The plug MUST be plugged into a matching outlet that is properly installed and grounded in accordance with ALL local codes and ordinances. -
Page 7: Know Your Heat Gun
KNOW YOUR HEAT GUN A - HEAT GUN NOZZLE B - ON/OFF SWITCH C - AIR INLET GRILLS FOR FAN OPERATION Use this versatile device for stripping paints and varnishes, thawing frozens pipes, softening adhesives for removal of linoleum and floor tile and removing stickers and labels. 1) Securely insert the plug of the heat gun into an AC 120V 60 Hz receptacle. -
Page 8: Exploded View And Parts List
EXPLODED VIEW AND PARTS LIST Item Stock # Description Item Stock # Description 2020-001 Left side housing 2020-013 Motor 2020-002 Mica paper 2020-014 Diode 2020-003 Steel sleeve 2020-015 Trigger 2020-004 Locating ring 2020-016 Switch 2020-005 Front cover 2020-017 Terminal 2020-006 Heat coil set... - Page 9 LIMITED TWO YEARS WARRANTY WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
- Page 10 Thanks for remembering...
