Wen 23190 Manual

Variable speed rotary tool kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

3065544
For replacement parts visit
WENPRODUCTS.COM
Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.
VARIABLE SPEED
ROTARY TOOL KIT
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
Model # 23190
bit.ly/WENvideo
(M-F 8AM-5PM CST)

Advertisement

Table of Contents
loading

Related Manuals for Wen 23190

Summary of Contents for Wen 23190

  • Page 1 WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.

  • Page 2: Table Of Contents

    Know Your Rotary Tool Assembly and Adjustments Operation Maintenance Exploded View & Parts List Warranty PRODUCT SPECIFICATIONS Model Number: 23190 Motor: 120 V, 60 Hz, 160W Speed: 8,000 - 35,000 RPM Collet Size Capacity: Max 1/8 in. (3.2 mm) Assembled Product Weight:...

  • Page 3: General Safety Rules

    You know the drill. The purpose of the following safety symbols is to attract your attention to possible dangers. We don’t want any of our beloved WEN customers accidentally injuring themselves. The safety symbols and the explanations with them deserve your careful attention and understanding. The safety warnings do not by themselves eliminate any danger.
  • Page 4 GENERAL SAFETY RULES Safety is a combination of common sense, staying alert, knowing how your item works, and not doing dumb stuff on purpose. SAVE THESE SAFETY INSTRUCTIONS. WARNING: To avoid mistakes and serious injury, do not plug in your tool until the following steps have been read and understood.

  • Page 5: Rotary Tool Safety Rules

    GENERAL SAFETY RULES 15. DO NOT OVERREACH. Keep proper footing and balance at all times. Wear oil-resistant rubber-soled foot- wear. Keep the floor clear of oil, scrap, and other debris. 16. MAINTAIN TOOLS PROPERLY. ALWAYS keep tools clean and in good working order. Follow instruc- tions for lubricating and changing accessories.

  • Page 6: Electrical Information

    ELECTRICAL INFORMATION DOUBLE INSULATION Double insulation is a concept in safety in electric power tools, which eliminates the need for the usual three-wire grounded power cord. All exposed metal parts are isolated from the internal metal motor components with protecting insulation. Double insulated tools do not need to be grounded. WARNING: The double insulated system is intended to protect the user from electric shock resulting from a break in the tool’s internal insulation.

  • Page 7: Know Your Rotary Tool

    KNOW YOUR ROTARY TOOL Collet Lock Button Hook Locking Collar Collet Nut Rotational Speed Wheel Steady Grip Attachment ASSEMBLY AND ADJUSTMENTS STEADY GRIP ATTACHMENT Your rotary tool can be used in two configurations, depend- ing on your personal preference and the requirement of the project.
  • Page 8 ASSEMBLY AND ADJUSTMENTS INSTALLING THE ROTARY BITS 1. Make sure that the tool is unplugged before attempting any tool adjustments. 3. Hold down the collet lock button and rotate the collet nut until the lock engages. 4. Using the included wrench, loosen the collet nut and remove it from the tool. Release the collet lock button. 5.
  • Page 9 ASSEMBLY AND ADJUSTMENTS Refer to the chart below for explanations and recommended applications for your rotary bits. Accessory Explanation Application Felt Polishing Wheel Finishing processes for smoothing Cleans, polishes & buffs metal, wood, and plas- tic. Attached to screw mandrel. a workpiece’s surface.
  • Page 10 ASSEMBLY AND ADJUSTMENTS ATTACHING THE FLEX SHAFT FOR VIDEO INSTRUCTIONS VISIT: http://bit.ly/wenflexshaft 1. Unscrew and remove the locking collar fromn the end of the rotary tool. 2. Take the flex shaft and slide the inner core out about 2-3”. 3. Loosen the collet nut by pressing down on the collet lock button and unscrewing the collet nut. Make sure that the collet being used is appropriate for the flex shaft’s inner core 4.

  • Page 11: Operation

    OPERATION WARNING: Read and thoroughly understand all instructions and safety information before operat- ing this rotary tool. Failure to do so may cause serious injury or death. As with all power equipment, a rotary tool can be dangerous if it is not assembled or used properly. Do not operate this power tool if you have doubts or questions regarding operation safety.

  • Page 12: Exploded View & Parts List

    EXPLODED VIEW AND PARTS LIST...
  • Page 13 EXPLODED VIEW AND PARTS LIST Part No. Description Quantity 23190-001 Collet Nut 23190-002 Collet 23190-003 Cap Body 23190-004 Spindle Lock Button 23190-005 Gasket 23190-006 Axis Locking Button 23190-007 Spring of Spindle Lock 23190-008 Rotor 23190-009 Carbon Brush 23190-010 Screw 23190-011...
  • Page 14 LIMITED ONE YEAR WARRANTY WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of one (1) year from date of purchase.
