Step 8:
Set the HIGH ALARM settings for VALUE (the reading
that will give a High Alarm) and NOTIFICATION. Press
ENTER to confirm and go to the previous page
>mA INPUT 1 HIGH ALARM<
VALUE
High Alarm
ALARM NOTIFY
USE NUMBER KEYS TO CHANGE, PRESS
ENTER TO ACCEPT OR BACK TO ERASE
Step 9:
Set the value of the ALARM NOTIFY by using the
arrow keys. Then press ENTER to confirm and go to the
previous screen.
Note: Display - will appear on controller display only,
Remote - appears through email if controller is online, or
both Dis/Remote
>mA INPUT 1 HIGH ALARM<
VALUE
ALARM NOTIFY (OFF
ALARM NOTIFY
USE UP/DOWN KEYS TO CHANGE
PRESS ENTER TO ACCEPT
Step 10:
Repeat Steps 19 and 20 for the LOW ALARM.
Press BACK to return the mA Input 1 Set Points
>mA INPUT 1 SETPOINT CHANGE<
SET POINT
DIFFERENTIAL
HIGH ALARM
LOW ALARM
LIMIT TIME
00020 %)
[__ ] %
)
--> OFF
Step 11:
Set the value of LIMIT TIME by using the number
keys. Then press ENTER to confirm and go to the
previous screen. The Limit Time and the Alarm
Notification will need to be set. Press HOME
when finished to return to the HOME menu
>mA INPUT 1 SETPOINT CHANGE<
SET POINT
DIFFERENTIAL
HIGH ALARM
LOW ALARM
LIMIT TIME
Note: If the Limit Time is met a relay activated by
the 4-20mA input will be forced off until the Set
Point has been satisfied and reset.
