Pressure Setpoint Configuration Procedure
If these are improperly set by entering an A/D value
for the settings while the input is not seeing the
correct signal a signal generator will be required to
reset the calibration.
Step 1:
Push the HOME button to leave Calibration and go back
to the HOME menu screen. From here push SETPOINTS
(Button 1) to go to the next screen
>HOME SETUP<
SETPOINTS
CALIBRATION
TIMERS
CUSTOMIZE
ALARMS
Step 2:
This is the Setpoints Setup Screen. From here push mA
IN (Button 7) to go to the next screen
>SETPOINTS SETUP<
SENSORS
Step 3:
This is the mA Inputs Screen. From here push INPUT 1
(Button 1) to go to the next screen
>mA INPUTS<
INPUT 1
Step 4:
This is the mA Input 1 Setpoint Review Screen. From here
push SETPOINTS (Button 5) to go to the next screen
>mA INPUT 1 SETPOINT<
mAIN1
SET POINT:
DIFFERENTIAL:
HIGH ALARM AT:
LOW ALARM AT:
LIMIT TIME:
SETPOINTS
DATE/TIME
CONFIGURE
HISTORY
TOTALIZERS
RELAYS
mA IN
500%
RISING CONTROL
20
1000(OFF
)
0(OFF
)
00:01 HH:MM
Step 5:
This is the mA Input 1 Setpoint Change Screen.
From here you can set SET POINT (Button 1),
DIFFERENTIAL (Button 2), HIGH ALARM
(Button 3), LOW ALARM (Button 4) and LIMIT
TIME (Button 5). Press the desired button to go
to the next screen
>mA INPUT 1 SETPOINT CHANGE<
SET POINT
DIFFERENTIAL
HIGH ALARM
LOW ALARM
LIMIT TIME
Step 6:
Set the value of SET POINT by using the number
keys.
Use the left arrow to set the reaction
direction of the set point between RISING or
FALLING. Then press ENTER to confirm and go
to the previous screen
>mA INPUT 1 SETPOINT CHANGE<
SET POINT (RISES TO 00500
SET POINT
DIFFERENTIAL
HIGH ALARM
USE NUMBER KEYS TO CHANGE, PRESS
ENTER TO ACCEPT OR BACK TO ERASE
LOW ALARM
LIMIT TIME
Step 7:
Set the value of DIFFERENTIAL by using the
number keys. Then press ENTER to confirm and
go to the previous screen
>mA INPUT 1 SETPOINT CHANGE<
DIFFERENTIAL 00020
SET POINT
DIFFERENTIAL
HIGH ALARM
USE NUMBER KEYS TO CHANGE, PRESS
ENTER TO ACCEPT OR BACK TO ERASE
LOW ALARM
LIMIT TIME
8
%)
[RISES][__
] %
%)
[__
] %
