4.3 Recycle Timer
>SYSTEM 1 TIMER 1 CHANGE<
ON CYCLE (HH:MM)
OFF CYCLE (HH:MM)
OFF TIMER (HH:MM:SS): 0:10:40
4.7 28-Day Timer
Each 28-day timer has Program 1-4 for programming the various feed times. While the programming steps
for four programs are the same each can have it's own independent settings.
>SYSTEM 1 TIMER 1 CHANGE<
WEEKS
DAYS
START TIME
RUN TIME
5. Customize
This menu allows the user to define the on-screen name of the unit plus the name of each system and relay.
The user can also setup the Notepad for each system and 4-20mA Input's name and unit of measurement.
>CUSTOMIZE<
UNIT NAMES
RELAY NAMES
SYSTEM 1 NAME
NOTE: When entering values for custom names use the numerical keys for numbers and the up / down
arrows to scroll through all the characters of a key board. Press the right arrow to advance the curser after
setting a desired value. Press the Help button to place the last entered character into the new cursor space
to speed up the process. The Help button will also jump advance through the characters.
5.1 Notepad
The Notepad function allows the user to set up a customized manually entered data field for each system
with ten notepad items. The NOTEPAD is ideal for setting up and storing into the controller's history the items
typically tested for reporting a service call. The Notepad items come with no names but when an individual
note is selected a menu for setting it appears.
Also can be used as a Reminder Timer with or without flow.
ON CYCLE - The amount of the defined time that the
timer is to be on.
OFF CYCLE - The amount of time that the cycle is
going to be on.
ON/OFF TIMER - This is the displayed count down of
time for the cycle the timer is in.
WEEKS - The week(s) that the timer is to feed.
DAYS - The day(s) that the timer is to feed.
START - The time of day for the timer to start.
FEED LOCK
RUN - How long the timer is to run.
FEED LOCK - Which other system timer to lockout
during this timer's run time.
FLOW LOCK
FLOW LOCK - If the system has a flow switch you can
ignore it for this timer.
RUN SCREEN - Allows the user to select what will be
shown on the screen while the controller is in the RUN
mode.
NOTEPAD
meter totals for a particular system or the conductivity
pH INDEX
units of measure.
mA IN
RUN SCREEN
15
Like displaying temperature readings, water
