a reference. A 20mA input should be around 5500 and 4mA around 1100. If the A/D numbers are not in this
range check input device.
The MAX and LOW calibration inputs are for telling the controller what to display for a 20mA input and a 4mA
input. For example if the input is a drum level sensor monitoring a 55 gallon drum the value for MAX should
be 55 and LOW should be 0. The controller then displays a number automatically ranging between 55 and
0 based on the input value. The units of measure (gallons for example) is set in the Customize menu from
the Home page.
OFFSET - Changes the current displayed value of the 4-20mA input reading to allow for a manual 1pt
calibration of the displayed value.
FACTORY DEFAULT - If the 20mA or 4mA calibration has been incorrectly set (not at 4 or 20) this will reset
the settings back to a factory value for 4 and 20.
4. Timer
A unit may have up to (1) timer standard for each system on a controller. All timers are associated with their
system, so for a % of post bleed timer looks at the bleed of that system.
>SYSTEM 1 TIMER<
TIMER 1
4.1 Timer Type Selection
A pop-up screen lets you scroll through the various timer types available.
>SYSTEM 1 TIMER 1 SET UP<
>SET TIMER TYPE (PULSE)<
-> PULSE
USE UP/DOWN KEYS TO CHANGE
PRESS ENTER TO ACCEPT
SET UP
4.2 Timer Set Up
>SYSTEM 1 TIMER 1 SET UP<
TIMER TYPE: PULSE
GALLONS: 10
RUN TIME (MM:SS): 01:00
INPUT: WATER METER 1
SET UP
TIMER - Select the type (28-day, pulse, limit, percent or
percent of post blowdown) as well as the run times of
each timer available per system.
* Pulse - A water meter activated timer
* Limit - Feed with bleed with a maximum run time or
limit for one bleed cycle.
Recycle - A continuous recycle timer with ON and OFF
settings.
* Percent Post Bleed - For feed after bleed for a
settable percentage of the bleed time with a maximum
TIMER TYPE
run time.
28-Day - A biocide or event timer.
* Main timer types used
Each timer type selected will have its own unique Set
Up sub menu with additional selections specific to
the type of timer selected. The page displayed before
entering the Set Up menu of a timer provides an overall
review of the timers current settings.
TIMER TYPE
