8. Configure
Provides access to menus to set-up passwords, relay activation, temp scale, display contrast, flow switch,
inputs, history time stamps, factory set-up and system information.
>CONFIGURE<
PASSWORD
RELAYS
HISTORY
FLOW SW
8.1 Password
>CONFIGURE PASSWORDS<
ADMIN PASSWORD
USER PASSWORD
USER SET UP
8.2 Relays (factory pre-configured)
>RELAY 1 SETUP<
MAIN ACTION
ACTIVATOR 2
ACTIVATOR 3
ACTIVATOR 4
DELAY
Additional relay logic is available with up to 3 additional Activators and up to 4 Disablers allowing multiple
functions to activate the same relay and multiple functions to prevent the relay from coming on. There is
also a Daily Max amount of time that a relay can be on. If a relay is on for the max amount it does not let
the relay come on anymore that day. (A 24 hour clock is used for the day with midnight being the start of
the day). The Delay setting is the amount of time a control function must come on before the relay will
react and activate. This is to prevent a relay from chattering on/off if a reading is bouncing around the set
point or alarm.
8.3 History
This menu is used to set the history "time stamp" interval, the water meter daily history starting hour and the
alarm delay period.
>CONFIGURE HISTORY<
INTERVAL
W/M HOUR
ALARM DELAY
CONTRAST - This screen allows for adjusting the
display contrast.
CONTRAST
FLOW SW - Defines a flow switch to be open or closed
TEMP SCALE
with flow.
NETWORK
FACTORY - A factory only menu
TEMP SCALE - Set Celsius or Fahrenheit
SYS INFO
HISTORY - Sets the history time stamp interval.
FACTORY
SYS INFO - Tells unit software specifics.
ADMIN PASSWORD - The administrator password
gives access to all menus except factory set up.
USER PASSWORD - The user password allows the
user to access HOME menus that are made available
in USER SET UP.
CONFIGURE RELAYS - This menu lets you choose a
Main Action or function (timer 1, conductivity, alarms
DISABLE 1
etc...) to activates a relay.
DISABLE 2
DISABLE 3
A pop-up screen appears with a list of all available
activation functions to arrow through.
DISABLE 4
DAILY MAX
INTERVAL - The amount of time between each history
time stamp for probe readings.
W/M HOUR - The time of day that the daily water
meter history cycle is to start.
ALARM DELAY - The amount of time an alarm has to
be on before it is recognized as an alarm.
