8.4
Flow Switch
This menu allows the user to select if a flow switch signal will represent a flowing condition when a "closed"
or "open" signal is seen for each systems flow switch input. User can also select if timers can work always
or only with flow.
8.5
Contrast
This menu is used to adjust the contrast of the display.
8.6
Temperature Scale
This menu is used to select the type of temperature scale to display.
8.7
Network (if applicable)
The Network menu is used when a controller is being remotely communicated with either a local network
connection or over the internet on the Web Advantage server.
>CONFIGURE NETWORK<
IP ADDRESS
IP MASK
GATEWAY
SERVER
HTTP LOCAL
8.8
System Information
System information will identify the version of firmware installed in the controller along with the controller's
serial number.
9.
History
The onboard history allows for viewing the history of the probe readings, relay activations, key-pad activity,
calibrations, water meter hourly and daily logs and alarms for each system present. It is also where Notepad
data is entered and reviewed. An initial overview page is displayed showing your current sample interval, the
calculated number of days the unit can keep probe history for before losing the oldest. The number of sensor
samples and relay/alarm events and Notepad entries currently stored is also displayed.
>HOME REVIEW<
SYSTEM 1
Sample Time: 5 MIN
(Length 164.62 days)
Relay/Alarm Events
HTTP REMOTE
FTP
RESET
Sensor Samples
882
323
Notepad Entries
NETWORK - This menu is used for setting up the
remote WebAdvantage communications and is
covered in a separate manual.
NOTE: The history can be reset by going to the
configure menu and entering a different sample
interval. After the new sample interval has been set
the onboard history is reset.
18
