9.1 Viewing History
>HISTORY<
RELAY LOGS
ALARM LOGS
SENSOR HISTORY
EVENT LOG
NOTEPAD
9.2 Notepad Entries
>NOTEPAD: SYS 1 NOTE 1<
ENTER VALUE
LOG
GRAPH
11. Relays
>RELAYS<
STATUS
RESET
FORCE
>RELAY STATUS<
R01: ON
SYS1 COND BLEED
R02: OFF
SYS1 pH
R03: OFF-T
SYS1 TIMER1 INH
R04: OFF
SYS1 TIMER2 BIO1
R05: OFF
SYS1 TIMER3 BIO2
WATER METER
Total Hardness
8 Entries
517.2 Hrs to Alarm
006:30:30
008:56:35
011:00:10
007:00:00
008:10:30
RELAY LOGS - Relay activations displayed in a log
form. Arrow up to advance through the log.
ALARM LOG - Alarm activations in log form.
SENSOR HISTORY - For selecting the parameters
and viewing of a given probe reading's history in log or
graph form.
EVENT LOG - Displays various activities.
The Notepad section under History is where the user
goes to enter new values for the customized notepad
items. Each individual notepad item's manually
entered entries are stored in the units history and
can be reviewed in log or graph form after 4 or more
values have been entered.
STATUS - Allows for viewing accumulated relay ON
times, temporary forcing relays ON or OFF or seeing
which relay is on.
RESET - Allows the accumulated run time of a
particular relay to be reset to zero.
FORCE - Allows a relay to be manually forced ON
for a single event from 0-99 minutes. When the event
is over the relay goes back to it's normal automatic
.
control
In the STATUS view the accumulated ON time is
shown along with the main activator, custom name and
current status:
ON = Relay on by relay activators
OFF = Relay off by normal logic
OFF-T = Relay off for daily max
OFF-D = Relay off for relay disabler
ON-A = Relay activated by activator other than main
action
H-ON = Relay manually forced on
H-OFF = Relay manually forced off
