6.2 Right Panel
1
OPTICAL IN
Connect to the audio source's optical output.
2
COAX IN
Connect to the audio source's coaxial output.
3
L/R IN
Connect to the analog audio source with a stereo RCA cable.
6.3 Left Panel
1
L/R OUT
Connect to a compatible audio equipment, such as a TV or
amplifier with a stereo RCA cable.
2
COAX OUT
Connect to an audio system's coaxial input.
3
OPTICAL OUT
Connect to an audio system's optical input.
4
1
3
2
1
2
3
