- Page 1 JTD-322 JTD18G-H5CH GUIDE J-TECH DIGITAL J-TECH DIGITAL SUPPORT TEAM 1-888-610-2818 SUPPORT@JTECHDIGITAL.COM...
- Page 2 JTD-322 JTD18G-H5CH GUIDE The JTD18G-H5CH audio extractor "extracts" the audio signal from an HDMI input and converts it into a 2 channel L/R analog stereo output or SPDIF optical multi- channel output. This guide provides the instructions you will need to properly setup, connect and operate your JTD18G-H5CH audio extractor.
- Page 3 FRONT PANEL DC 5V: This unit uses a DC 5V/1A power adapter POWER LED: This LED will illuminate to indicate that the unit is receiving power EDID SWITCH Allows users to select the audio EDID (Extended Display Identification Data) format according to TV, 5.1 Channel, or 2 CH: TV: Bypass or pass-through mode.
- Page 4 REAR PANEL HDMI OUT: Output source HDMI audio/video. L/R OUT: Connect to an audio component (speaker, amplifier, etc.) or TV L/R input. SPDIF/OPTICAL: Output PCM/2CH or 5.1 Dolby Digital audio formats (NOTE: The SPDIF/Optical output will support PCM/2CH, and 5.1 Dolby Digital audio format.
- Page 5 Application Description...
