6. OPERATION CONTROLS AND FUNCTIONS
6.1 Top Panel
1
POWER LED Indicator
The LED will illuminate in blue when the power is connected and in
red when switched off.
2
Dolby Digital LED Indicator
When the source is Dolby Digital formatted the LED will illuminate in
red and will remain off if not.
3
L/R IN LED Indicator
When selecting the L/R input, the blue LED will turn on.
4
COAX IN LED Indicator
When selecting the Coaxial input, the blue LED will turn on.
5
OPTICAL IN LED Indicator
When selecting the Optical input, the blue LED will turn on.
UNIVERSAL
Dolby DIGITAL / ANALOG
AUDIO CONVERTER
POWER
D L/R COAX OPTICAL
1
2
3
4
5
3
