Exabyte Mammoth Field Instructions

8mm tape drive replacing the scsi card
Hide thumbs Also See for Mammoth:
1
2
3
4
5
6

Advertisement

Table of Contents

Exabyte Field Instructions
December 1997
Replacing the SCSI Card in an
Exabyte
319931-001

®
Mammoth 8mm Tape
Drive
1
Before you begin . . . . . . . . . . . . . . . . . . . . . . . 2
2
Removing the SCSI card . . . . . . . . . . . . . . . . . 3
3
Installing the SCSI card. . . . . . . . . . . . . . . . . . 5
4
After you replace the SCSI card . . . . . . . . . . . 6
Contents

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mammoth and is the answer not in the manual?

Questions and answers

Related Manuals for Exabyte Mammoth

Summary of Contents for Exabyte Mammoth

  • Page 1 Replacing the SCSI Card in an ® Exabyte Mammoth 8mm Tape Drive Contents Before you begin ..... . . 2 Removing the SCSI card .
  • Page 2 Copyright 1996-1997 by Exabyte Corporation. All rights reserved. This item and the information contained herein are the property of Exabyte Corporation. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer...
  • Page 3 2 Removing the SCSI card Required tools  Torque limiting screwdriver  T-6 TORX bit Removing the SCSI card 1. Turn the tape drive upside-down. Using a T-6 screwdriver, remove the two side screws and one rear screw that secure the bottom cover to the tape drive, as shown in Figure 1.
  • Page 4 ® Replacing the SCSI Card in a Exabyte Mammoth 8mm Tape Drive Figure 2 Removing the SCSI card 4. The SCSI connector is located on the underside of the SCSI card, on the left side (see Figure 2). To disengage the SCSI connector, lift the left edge of the card.
  • Page 5 3 Installing the SCSI card Installing the SCSI card 1. Remove the replacement SCSI card from its antistatic bag. 2. Handling the card by its edges, position the card with the SCSI connector on the left. The hooked edge of the card goes around the right rear edge of the MRC card (see Figure Figure 3 Replacing the SCSI card...
  • Page 6  Set the tape drive SCSI ID  Attach the power cable and SCSI cable  Power on the tape drive  Perform diagnostic tests Refer to Exabyte Mammoth Installation and Operation (part number 306484) for instructions. Page 6 of 6 319931...
