Cubetape PRO Quickstart Guide
Exterior Overview
Press to record measure
Scan barcode
Power On/O
To turn on the device, press
To shut down the device, press
on screen (or 5 beeps are heard).
Taking Measurements
While the cursor is in the length field, extend the blade and take the measurement (L, W or H), press
to capture the measurement.
Return to Last Recorded Data
Press
several times until the cursor is in the length field;
Press
this will display the last recorded measurement on screen.
www.averyweigh-tronix.com/cubetape
USB Port
Charge Light
LED
Send data record
Append; save data
once.
for approximately 3 seconds, then release when "power off" is indicated
Tape Tip
Tape Tip
Rubber Boot
Backspace; power on/off
All buttons can be used for navigation
under menu mode except for
Battery Compartment
Tape Cassette
or
1
Advertisement
Table of Contents
Related Manuals for Avery Weigh-Tronix CUBETAPE PRO
Summary of Contents for Avery Weigh-Tronix CUBETAPE PRO
- Page 1 Cubetape PRO Quickstart Guide Exterior Overview USB Port Charge Light Tape Tip Battery Compartment Tape Tip Rubber Boot Tape Cassette Send data record Press to record measure Backspace; power on/off Append; save data Scan barcode All buttons can be used for navigation...
- Page 2 A battery indicator symbol appears at the left bottom of the screen. The symbol displays the percentage of battery life remaining. To charge the battery, connect Cubetape PRO to a PC or power adaptor via the USB cable. The charge light remains on during the charging process.
