Pima Sentinel Installation And Configuration Manual page 43

Code Description
55 Repeater 10 Channel 1 Fail
56 Repeater 10 Channel 2 Fail
57 Repeater 10 Channel 3 Fail
58 Repeater 10 Channel 4 Fail
59 Repeater 11 Channel 1 Fail
5A Repeater 11 Channel 2 Fail
5B Repeater 11 Channel 3 Fail
5C Repeater 11 Channel 4 Fail
5D IP Receiver Fail
5E IP Receiver Cellular Multiple Offline
5F IP Receiver Ethernet Multiple Offline
60 Tamper Open
61 Zone 1 Open
62 Zone 2 Open
2
63 AC Fault
64 Low Battery Fault
65 Repeater 12 Channel 1 Fail
66 Repeater 12 Channel 2 Fail
67 Repeater 12 Channel 3 Fail
68 Repeater 12 Channel 4 Fail
69 Repeater 13 Channel 1 Fail
6A Repeater 13 Channel 2 Fail
6B Repeater 13 Channel 3 Fail
6C Repeater 13 Channel 4 Fail
6D Repeater 14 Channel 1 Fail
6E Repeater 14 Channel 2 Fail
6F Repeater 14 Channel 3 Fail
70 Repeater 14 Channel 4 Fail
71 Repeater 15 Channel 1 Fail
72 Repeater 15 Channel 2 Fail
73 Repeater 15 Channel 3 Fail
74 Repeater 15 Channel 4 Fail
75 Repeater 16 Channel 1 Fail
76 Repeater 16 Channel 2 Fail
77 Repeater 16 Channel 3 Fail
78 Repeater 16 Channel 4 Fail
79 Not in use
7A Invalid Account Addition
7B Invalid Repeater Event
7C Pattern Error
7D Call ID\IP Error
7E Critical Temperature
7F General Fault
1 If a repeater test/fail account is set, the repeater faults are sent with TN in "DOS Compatible"
mode or 334 if not. Else, they are sent with the above fault codes
2 SAR-100 codes
3 "SpeedFan © " or any other temperature monitor code
4 Includes "Invalid Repeater Event", "SENTINEL Fault", "Not Enough Memory is Available" and
any undefined error. Not all general faults have a restore event
1
1
1
1
1
1
1
1
2
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
4
Code Description
D5 Repeater 10 Channel 1 Restore
D6 Repeater 10 Channel 2 Restore
D7 Repeater 10 Channel 3 Restore
D8 Repeater 10 Channel 4 Restore
D9 Repeater 11 Channel 1 Restore
DA Repeater 11 Channel 2 Restore
DB Repeater 11 Channel 3 Restore
DC Repeater 11 Channel 4 Restore
DD IP Receiver Restore
DE IP Receiver Cellular Multiple Offline Restore
IP Receiver Ethernet Multiple Offline Re-
DF store
E0 Tamper Restore
E1 Zone 1 Restore
E2 Zone 2 Restore
2
E3 AC Restore
E4 Low Battery Restore
E5 Repeater 12 Channel 1 Restore
E6 Repeater 12 Channel 2 Restore
E7 Repeater 12 Channel 3 Restore
E8 Repeater 12 Channel 4 Restore
E9 Repeater 13 Channel 1 Restore
EA Repeater 13 Channel 2 Restore
EB Repeater 13 Channel 3 Restore
EC Repeater 13 Channel 4 Restore
ED Repeater 14 Channel 1 Restore
EE Repeater 14 Channel 2 Restore
EF Repeater 14 Channel 3 Restore
F0 Repeater 14 Channel 4 Restore
F1 Repeater 15 Channel 1 Restore
F2 Repeater 15 Channel 2 Restore
F3 Repeater 15 Channel 3 Restore
F4 Repeater 15 Channel 4 Restore
F5 Repeater 16 Channel 1 Restore
F6 Repeater 16 Channel 2 Restore
F7 Repeater 16 Channel 3 Restore
F8 Repeater 16 Channel 4 Restore
-- --
-- --
-- --
-- --
-- --
FE Critical Temperature Restore
FF General Fault Restore
Fault Codes
1
1
1
1
1
1
1
1
2
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
4
43
