Creative Structures Sound Blaster 16 Getting Started page 45

Table D-6: 26-pin DRAM Upgrade connector pin assignments.
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
D-6 Hardware Information
This manual downloaded from http://www.manualowl.com
Description
RAMDIS
SD15
SD13
SD11
SD9
Digital Ground
SMCAS
Digital Ground
Digital Ground
SMA16
SMA6
SMA4
VCC
Pin Description
2 VCC
4 SD14
6 SD12
8 SD10
10 SD8
12 Digital Ground
14 MODE
16 Digital Ground
18 Digital Ground
20 SMA7
22 SMA5
24 SMA18
26 VCC
