DRAM Upgrade Connector Pin Assignments

There are two DRAM Upgrade connectors on your card. Each has a
different set of pin assignments as shown in Table D-5 and Table D-6.
Table D-5: 24-pin DRAM Upgrade connector pin assignments.
Pin
1
3
5
7
9
11
13
15
17
19
21
23
This manual downloaded from http://www.manualowl.com
Description
VCC
SDO
SD2
SD4
SD6
Digital Ground
WRB
Digital Ground
SMA19
SMA1
SMA3
NC
Pin Description
2 VCC
4 SD1
6 SD3
8 SD5
10 SD7
12 Digital Ground
14 SMRAS
16 Digital Ground
18 SMA0
20 SMA2
22 SMA20
24 VCC
Hardware Information D-5
