Javad HPT435BT JL User Manual page 15

Figure 19. HPT435BT JL Status NTRIP tab
7. Connect Serial Port. Use any application to connect serial port of
HPT435BT JL using the following parameters:
• Baudrate 115200
• Parity none
• Data Bits 8
• Stop Bits 1
• Handshake hardware
...Setup HPT435BT JL to provide RTK data received via
UHF channel (in Satel mode) to Serial Port
The following are the steps of configuration of HPT435BT JL:
1. Connect to HPT435BT JL via web interface as described above.
2. UHF configuration in Satel mode:
In the Communication/UHF Int. tab:
• select operating frequency or add new frequency to the list
• select Protocol type Satel
select channel bandwidth (spacing) either 25.0 or, 20.0, or 12.5 kHz
www.javad.com
verify FEC (Forward Error Correction) state is correct
Figure 20. HPT435BT JL UHF parameters configuration tab
In the Communication/Power Management tab activate the UHF inter-
face:
Figure 21. HPT435BT JL Power Management tab
Detailed connection status you can check in Status/UHF int. tab
15
