Slow-flashing white light indicates an
error has occurred.
The pinsetter needs attention. Turn
machine off and lock out power before
servicing.
Solid white light indicates the pinsetter is
READY TO RUN. A signal from a
remote location will cause the pinsetter
to start WITHOUT WARNING. Stay
clear of machine. Keep guards in place.
No light indicates the pinsetter is off.
Safe to Service. Lock out power
before servicing.
Figure 2- 3. StringPin Pinsetter Status Light
2-4
Section 2: Overview
