4
• Pinch hazard. Make certain that hands or fingers are not in the way to be caught
when operating clutch lever.
Drive Clutch Lever
3577M-6107-0402-010
Shift Lever
Aux. Shift Lever
3577M-6107-0402-110
Throttle Lever
Fast
3577M-0402-121US
Operation
Stop
3/6 1/4 High
N
2/5 R1/R2 Low
1. Make certain of the safety of your surround-
ings.
2. Make certain that drive clutch lever is in
[Stop] position.
3. Move Shift lever and Auxiliary (aux.) shift
lever into a desired position.
NOTE
• Refer to "Product Specifications" (Page 11)
for speed in each gear.
• When it is difficult to shift gears, move drive
clutch lever toward [Run] position slightly
and try again. It may help shifting smoothly.
4. Move throttle lever to [Fast] position to raise
engine speed.
