How To Use Can And Cam Post Hardware; Step 1 - modway EEI -1324 Assembly Instructions Manual

EEI -1324
DESK

HOW TO USE CAN AND CAM POST HARDWARE

1.
3.
5.
Note cam arrow
direction

STEP 1:

Place 1pc Side Drawer Front (F1),1pc Side Drawer Back (F4),1pc Left Drawer Side (F3), 1pc Right Drawer Side (F4)
and 1pc Side Drawer Bottom (F5) together as shown.
Attach them by 2pcs Cam Post (a), 2pcs Cam (b), 4pcs Screw (c), tighten the Screws (c) and Cam (b)
Fully tighten Cams (b), Screws (c) with Phillips Head Screw Driver (not included).
ax2 bx2 cx4
Customer Service 908-368-1025︱www.modwayfurniture.com
c
Phillips Head Screwdriver
( not included)
2.
4.
Turn cam clockwise
1/2 turn
b
F3
a
F5
F4
c
Hardware & Tools required
Note cam arrow
direction
F1
a
b
F2
Page 3 of 7
