CFA56
(6901-100095 <02>)
Thank you for choosing Sanus Systems Component Furniture. The CFA56 is designed to house
components weighing up to 18.1 kg (40lbs) on the top shelf, 22.6 kg (50 lbs) on the middle shelf, and 34
kg (75 lbs) on the bottom shelf.
CAUTION
Do not use this product for any purpose not explicitly specified
by Sanus Systems. Improper assembly may cause property
damage or personal injury. If you do not understand these
directions, or have doubts about the safety of the assembly,
contact Sanus Systems Customer Service or call a qualified
contractor. Sanus Systems is not liable for damage or injury
caused by incorrect assembly or use.
Sanus Systems 2221 Hwy 36 West, Saint Paul, MN 55113 USA
Customer Service: 1-800-359-5520 • info@sanus.com • www.sanus.com
