- Page 3 There are many small components used in the construction of this unit. These loose items should be kept away from young children while Shelf Pin P840048 x 8 P860121 x 1 Connector rod P860015 x 8 P820016T x 8 P816145 x 4 CAUTION assembling your unit.
- Page 4 Insert wooden dowels into sides as shown. 1. Fasten 8 Connector Rods into small holes in Top as shown.
- Page 5 Important: *When fitting the rails onto the top, ensure that the grooved part of the rails are closest to the side edges of the top. * The larger holes (cam holes) in the rails must always be closest to the Top. 1.
- Page 12 Locking screw x8 Base 1. With assistance align Base onto Dowels in Sides & Rails & then press fit. 2. Fasten large Locking screws through Base into Sides & Rails ( Screw heads should be flush with surface).
- Page 13 Following steps apply to both flat and curved front designs. Glide x6 Screw x6 1. Fasten the glides to the base as shown.
- Page 14 Adjusting screw x 4 1. Turn unit over carefully. 2. Screw each Adjusting screw into Side by half of it's visible threaded length, then once this is done, tighten all 4 Adjusting screws fully into Side.
- Page 15 Shelf Pin x8 1. Insert Shelf Pins into holes at the lower positions of both the Sides (as illustrated above). 2. Tilt and slide Glass Shelf between Rails (ensuring frosted side down) and place on top of Shelf Pins. 3. Insert Shelf Pins into holes at the upper positions of one Side only. 4.
- Page 16 1. Press fit 2 Cable Ducts into large holes in the Base. 2. You have now completed the assembly of your new Digital TV stand. NOTE: We recommend that all contents stored in or on this item of furniture be removed before shifting it. The manufacturers will not be held liable for damage caused when furniture is shifted without first removing its contents.
